Airtac MAC Stainless Steel Mini Air Cylinder MAC16X175SCA
$36.98
Regular price
$44.48
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MAC16X175SCA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MAC Stainless Steel Miniature Cylinder
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
Installation guidelines:
For vertical mounting, use ≤0.6MPa pressure to prevent seal overload.
Lubricate with ISO VG32 turbine oil if cycle rate exceeds 120cpm.
Allow 15mm front clearance for full stroke operation.
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
AirTAC MAC Stainless Steel Miniature Cylinder MAC16X175SCA Specifications
- Model: MAC16X175SCA
- Type: Single-acting spring return (push type)
- Bore size: 16mm
- Stroke: 175mm (±0.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Material: Stainless steel (SUS304 barrel/piston rod)
- Buffer type: Fixed rubber cushion
- Port size: M5x0.8 (standard) with NBR seals
- Temperature range: -20℃ to 80℃
- Mounting style: Basic type (no built-in mounting)
- Weight: 320g ±5g
- Dimensions:
- Length: 235mm (total extended length)
- Width: 28mm (max body diameter)
- Height: 28mm (including rod end)
- Rod thread: M6x1.0 external thread
- Corrosion resistance: Salt spray test passed 96hrs (NSS)
High-precision stainless steel mini cylinder featuring exceptional corrosion resistance and cleanroom compatibility. The electropolished surface (Ra≤0.4μm) prevents particle shedding, while the dual lip seal design ensures ≤0.5mm/s creep speed at 0.3MPa. Requires ISO 8573-1:2010 Class 3 compressed air.
Typical Applications:
- Pharmaceutical tablet press ejection mechanisms
- Semiconductor wafer handling robots
- Food packaging machines (NSF compliant)
- Laboratory liquid dispensing systems
- Cleanroom automation (ISO Class 5-8 environments)
Installation guidelines:
For vertical mounting, use ≤0.6MPa pressure to prevent seal overload.
Lubricate with ISO VG32 turbine oil if cycle rate exceeds 120cpm.
Allow 15mm front clearance for full stroke operation.
| Property | Property Value |
|---|---|
| sku | MAC16X175SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 175mm |
