Airtac MAC Stainless Steel Mini Air Cylinder MAC16X225SCM
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
AirTAC MAC16X225SCM Stainless Steel Mini Cylinder Specifications
- Model: MAC16X225SCM
- Type: Double-acting stainless steel cylinder
- Bore size: 16mm (ISO 6432 standard)
- Stroke: 225mm (adjustable cushioning)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 150℃
- Cushion type: Fixed rubber buffer + adjustable end lock
- Mounting style: Basic front flange (NF series compatible)
- Port size: M5×0.8 (G1/8 adaptor optional)
- Material: SUS303 stainless steel body, CR12MoV piston rod
- Seal material: Heat-resistant NBR + PTFE composite
- Weight: 1.25kg (without accessories)
- Dimensions:
- Length: 286mm (full extension)
- Body diameter: 22mm
- Mounting base: 35mm(W) × 20mm(H)
- Rod thread: M6×1.0 external thread
- Lubrication: Pre-lubricated (DOP anti-corrosion treatment)
High-precision corrosion-resistant mini cylinder with enhanced side load capacity through integrated guide design. Features vacuum-brazed stainless steel construction for ultra-clean environments. The chromium-plated piston rod incorporates a dual wiper system for particle containment. Requires 0.3μm filtered air with ISO 8573-1:2010 Class 2.4.2 air quality standard.
- Semiconductor wafer handling robots
- Pharmaceutical blister packaging machines
- Sterile laboratory automation
- Marine equipment actuators
- Food-grade production line pushers
- High-temperature oven door mechanisms
Installation protocol:
Use 316L stainless steel mounting hardware in corrosive environments.
Apply perfluoropolyether (PFPE) grease monthly in continuous operation.
Maintain 0.5mm minimum lateral clearance during alignment.
| Property | Property Value |
|---|---|
| sku | MAC16X225SCM |
| Rear Cover Type | Round Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 225mm |
