Airtac MAC Stainless Steel Mini Air Cylinder MAC16X225SU
$39.51
Regular price
$47.01
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MAC16X225SU
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MAC Stainless Steel Miniature Cylinder
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
Installation tip:
Use anti-vibration washers when mounting to aluminum frames. For vertical installations,
maintain 2mm minimum clearance under piston rod for thermal expansion. Lubricate every
500km of cumulative stroke movement.
1. Manufactured in compliance with AirTAC corporate standards;
2. Features custom bidirectional sealing profile with compact dimensions and integrated oil reservoir design for enhanced piston lubrication;
3. Equipped with fixed cushioning pads on both end caps to mitigate directional reversal impact;
4. Multiple rear cover configurations ensure versatile mounting flexibility;
5. Stainless steel barrel and end caps assembled through combined riveting and encapsulation process for robust connection;
6. Precision-engineered from high-grade stainless steel tubing offering exceptional corrosion resistance and structural integrity;
7. Comprehensive selection of cylinder specifications and mounting accessories available for customized applications;
8. Full-range magnetic version standard across series.
Category: Stainless Steel Miniature Cylinders | Brand: AirTAC | Series: MAC
AirTAC MAC16X225SU Stainless Steel Mini Cylinder Specifications
- Model: MAC16X225SU
- Type: Double-acting mini cylinder
- Bore size: 16mm
- Stroke: 225mm
- Operating pressure: 0.05–1.0 MPa (7-145 psi)
- Cushion type: Adjustable rubber cushion (both ends)
- Operating temperature: -20℃ to 80℃
- Mounting style: Basic type (optional flange/clevis kits available)
- Port size: M5x0.8 (standard), optional NPT1/8
- Material: Stainless steel (SUS304 barrel, aluminum end caps)
- Seal material: NBR (standard), optional FKM for high temp
- Weight: 640g ±2%
- Dimensions:
- Total length: 265mm (at full retraction)
- Body diameter: 25mm
- Mounting hole spacing: 30mm (front) / 22mm (side)
- Protection class: IP65 (standard wiper design)
- Lubrication: Pre-lubricated (use ISO VG32 turbine oil)
High-precision corrosion-resistant mini cylinder with smooth stroke control, featuring a stainless steel barrel for harsh environments. The compact MAC series combines 30% reduced footprint vs standard cylinders while maintaining 20kN maximum thrust capacity. Includes magnetic piston for position sensing compatibility.
Typical Applications:
- Semiconductor wafer handling robots
- Pharmaceutical blister packaging machines
- Coastal automation systems (saltwater resistant)
- Food processing conveyor actuators
- Cleanroom medical device assembly
Installation tip:
Use anti-vibration washers when mounting to aluminum frames. For vertical installations,
maintain 2mm minimum clearance under piston rod for thermal expansion. Lubricate every
500km of cumulative stroke movement.
| Property | Property Value |
|---|---|
| sku | MAC16X225SU |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 225mm |
