Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X100-CA-H
$31.24
Regular price
$38.74
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MAL20X100-CA-H
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AIRTRAC MAL20 Aluminum Miniature Cylinder Features:
1. Engineered with precision using high-grade aluminum alloy round tube barrel construction;
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
Installation guidelines:
1. Use Cushion Locknut (ASNU8) to secure stroke end positions
2. Maintain 0.3-0.5mm/m parallel alignment tolerance
3. For vertical mounting, add ESD10 shock absorber to prevent seal wear
4. Lubricate every 500km travel distance with ISO VG32 turbine oil
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X100-CA-H Aluminum Miniature Cylinder Specifications
- Model: MAL20X100-CA-H
- Type: Double-acting single piston rod
- Bore size: Ø20mm
- Stroke: 100mm (±0.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Port thread: M5×0.8 (standard) / PT1/8 optional
- Cushioning: Adjustable rubber buffer (both ends)
- Material: Anodized aluminum alloy barrel, CR12MoV piston rod
- Seal material: NBR (Nitrile Butadiene Rubber)
- Temperature range: -20℃ to 80℃ (dry air required below 0℃)
- Weight: 520g ±2% (without accessories)
- Dimensions:
- Total length: 167mm (stroke 100 + 67mm base)
- Barrel diameter: Ø32mm (hexagonal body)
- Mounting bracket: 50mm(W) × 20mm(H) front flange
- Rod thread: M10×1.25 (external)
- Max theoretical thrust: 61.5N @0.5MPa (extending)
- Lubrication: Pre-lubricated (oil-free operation possible)
- Protection rating: IP54 (standard), IP67 with optional wiper
Ultra-compact pneumatic cylinder featuring corrosion-resistant anodized finish and precision-ground piston rod. The hexagonal barrel design enables tool-free rotation adjustment during installation. Integrated magnetic piston enables position feedback when used with SNS series sensors (sold separately).
Ideal for:
- High-density automation cells in electronics manufacturing
- Medical device actuation requiring FDA-compliant materials
- Cleanroom-compatible machinery (low particle generation)
- Packaging line diverters with 500k+ cycle durability
- Robotic end-effector tooling under space constraints
Installation guidelines:1. Use Cushion Locknut (ASNU8) to secure stroke end positions
2. Maintain 0.3-0.5mm/m parallel alignment tolerance
3. For vertical mounting, add ESD10 shock absorber to prevent seal wear
4. Lubricate every 500km travel distance with ISO VG32 turbine oil
| Property | Property Value |
|---|---|
| sku | MAL20X100-CA-H |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
