Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X100-U
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X100-U Aluminum Miniature Cylinder Technical Details
- Series: MAL Aluminum Mini Cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 100mm (customizable 5-300mm)
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Port size: M5×0.8 (dual ports)
- Piston speed: 50-750 mm/s
- Rod material: Hard chrome-plated steel
- Seal type: NBR/PU seals (oil-resistant)
- Mounting: Basic type (optional foot/mounting flange)
- Weight: 350g ±2% (without accessories)
- Dimensions:
- Length: 155mm (minimum retracted length)
- Width: 34mm (cylinder body diameter)
- Height: 34mm (including mounting lugs)
- ISO standard: Compliant with ISO 6432:2015
- Protection class: IP40 (dust protected)
Ultra-compact aluminum cylinder optimized for space-constrained automation systems. Features precision honed tube (Ra≤0.4μm) and dual anti-rotation guide slots for stable linear motion. Requires filtered compressed air (5-40μm filtration) with recommended lubrication (ISO VG32). Includes built-in magnet for sensor compatibility.
- PCB handling robots in electronics manufacturing
- Precision clamping devices for CNC machining centers
- Pharmaceutical blister packaging machines
- Semiconductor wafer transfer mechanisms
- Automated test equipment positioners
Installation guidelines:
Maximum lateral load ≤5N. For vertical mounting, use mechanical lock at stroke end.
Lubricate every 3 months under normal operation (2,000 cycles/day). Avoid side load exceeding 0.3N·m.
| Property | Property Value |
|---|---|
| sku | MAL20X100-U |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
