Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X100-U-FA
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X100-U-FA Aluminum Miniature Cylinder Specifications
- Model: MAL20X100-U-FA
- Bore size: 20mm
- Stroke: 100mm
- Action type: Double-acting
- Mounting style: Front flange with axial mounting holes
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Material: Aluminum alloy body, NBR seals
- Temperature range: -10℃ to 80℃
- Protection rating: IP54 (standard)
- Weight: 0.45kg ±5%
- Dimensions: 160mm(L) × 40mm(W) × 40mm(H)
- Rod thread: M6x1 external thread
- Max theoretical thrust: 31.4N@0.5MPa
- Piston speed: 50–700mm/s
Ultra-compact pneumatic cylinder featuring precision-machined aluminum construction with anti-corrosion treatment. The MAL20 series delivers high thrust-to-size ratio through optimized seal geometry and low-friction guide rings. Integrated mounting flange enables direct installation in confined spaces. Requires 5μm filtered air with ISO VG32 hydraulic oil mist lubrication (optional oil-free operation available).
- PCB handling robots in electronics manufacturing
- Precision valve actuation in medical devices
- Labeling machine positioning mechanisms
- Semiconductor wafer transfer systems
- Automated test equipment clamps
Installation note:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use locking nuts on piston rod threads. Lubricate through
air supply (0.1cm³/min oil mist recommended for continuous operation).
| Property | Property Value |
|---|---|
| sku | MAL20X100-U-FA |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Front Flange Mounting Plate |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
