Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X25-U-H
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X25-U-H Aluminum Miniature Cylinder Specifications
- Model: MAL20X25-U-H
- Type: Single-acting spring return (push type)
- Bore size: 20mm
- Stroke: 25mm
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Rubber buffer
- Port size: M5×0.8 (G1/8 adaptor included)
- Piston rod thread: M6×1.0
- Seal material: Polyurethane (PU)
- Temperature range: -10℃ to 80℃ (operating), -20℃ to 100℃ (storage)
- Protection rating: IP54
- Weight: 180g ±5g
- Dimensions:
- Extended length: 98mm
- Retracted length: 73mm
- Body diameter: Φ32mm
- Mounting base: 30mm × 20mm
Ultra-compact aluminum cylinder with anodized surface treatment for corrosion resistance. Features precision-ground piston rod (hard chrome plated) and low friction seals for smooth operation. Includes magnetic piston for position sensing compatibility (sensor not included). Requires 40μm filtered lubricated air (ISO 8573-1 class 4).
- PCB handling robots in electronics assembly
- Precision clamping mechanisms
- Medical device actuation systems
- Textile machinery thread control
- Semiconductor wafer processing equipment
Installation note:
Maximum side load 3N. For vertical mounting, use locknut (AN6) to secure rod end.
Lubricate through air supply (ISO VG32 turbine oil recommended). Allow 5mm clearance
behind cylinder for spring chamber expansion.
