Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X50-U
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X50-U Aluminum Miniature Cylinder Specifications
- Model: MAL20X50-U
- Type: Single-acting spring return (push type)
- Bore size: 20mm
- Stroke: 50mm
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: PT1/8 (M5 optional)
- Cushion type: Rubber buffer (adjustable)
- Mounting style: Foot-mounted with 2x M5 threaded holes
- Material: Anodized aluminum alloy body, CRMo steel piston rod
- Seal material: NBR/PU compound seals
- Weight: 0.28kg
- Dimensions: 118mm(L) × 34mm(W) × 34mm(H)
- Rod thread: M6×1.0 external thread
- Max theoretical force: 25.1N @0.5MPa
- Speed range: 50–700mm/s
Ultra-compact pneumatic cylinder optimized for space-constrained automation systems. Features precision honed inner bore for smooth operation and nickel-plated piston rod for corrosion resistance. The MAL series incorporates a unique anti-rotation design with visible stroke markings, making it ideal for repetitive positioning tasks. Requires ISO 8573-1:2010 Class 3 compressed air.
- PCB handling robots in electronics assembly
- Dosing valve actuation in medical analyzers
- Precision clamping mechanisms for CNC tooling
- Automated shutter control in optical devices
- Textile machinery thread tension control
Installation tip:
For optimal performance, maintain 0.3-1.0mm clearance between rod end
and load during mounting. Lubricate with ISO VG32 pneumatic oil if
operating below -10℃. Avoid side loads exceeding 2.5N.
| Property | Property Value |
|---|---|
| sku | MAL20X50-U |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <50mm> |
