Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X50-U-FA
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X50-U-FA Aluminum Miniature Cylinder Specifications
- Model: MAL20X50-U-FA
- Type: Double-acting compact cylinder with magnetic piston
- Bore size: 20 mm
- Stroke: 50 mm
- Operating pressure: 0.1–0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5×0.8 (standard) / Optional PT1/8 adapter
- Cushioning: Adjustable rubber buffer (both ends)
- Material: Anodized aluminum body / Stainless steel piston rod
- Weight: 0.25 kg (without accessories)
- Dimensions: 25mm(W) × 25mm(H) × 103mm(L) (fully retracted)
- Mounting: Front flange (U-type) with 30mm mounting hole spacing
- Seal material: Heat-resistant NBR
- Piston speed: 50–800 mm/s
- Optional accessories: Magnetic switch (D-A93 series compatible)
A precision-engineered mini cylinder optimized for space-constrained automation systems. Features anti-corrosion anodization and dual cushioning for smooth operation. The integrated magnet in the piston enables position feedback when paired with sensors. Reduced air consumption design makes it energy-efficient for high-cycle applications.
- PCB handling robots in electronics manufacturing
- Precision valve actuation in medical devices
- Cartesian coordinate pick-and-place systems
- Compact clamping mechanisms in CNC tool changers
- Automated test equipment positioners
Installation guidelines:
Ensure proper alignment of piston rod axis (<0.2mm radial misalignment max).
Use clean, lubricated air (ISO 8573-1:2010 Class 2-4-3 recommended).
For vertical mounting, add 10% extra thrust margin for gravity compensation.
| Property | Property Value |
|---|---|
| sku | MAL20X50-U-FA |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Front Flange Mounting Plate |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <50mm> |
