This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is MBL25X75-U — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the MBL25X75-U in place of this model. The MBL replacement upgrades to a riveted rolling-packed body and the current CMSG / DMSG / EMSG sensor switches (the MAL used CS1-M / DS1-M).
Airtac MAL25 Aluminum Alloy Mini Cylinder MAL25X75-U
The AirTAC Airtac MAL25 Aluminum Alloy Mini Cylinder MAL25X75-U is a double-acting aluminum-barrel mini round cylinder with a Ø25mm bore and 75mm stroke, G1/8 air ports and a fixed rubber bumper. This model is discontinued — the drop-in replacement is the MBL25X75-U, which matches its bore, stroke, force and mounting.
- BoreØ25 mm
- Stroke75 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- StatusDiscontinued → MBL25X75-U
About the Airtac MAL25 Aluminum Alloy Mini Cylinder MAL25X75-U
The AirTAC MAL25X75-U is a discontinued compact double-acting aluminum mini round cylinder. Delivering 245 N of push force at 0.5 MPa, it features a 25 mm bore and 75 mm stroke. The exact drop-in replacement is the MBL25X75-U, which matches the original bore, stroke, output force, G1/8 port, and U flat-end back cover.
This legacy SKU features a U flat-end back cover for rigid rear mounting, and because it lacks an -S magnet, it cannot accept a position sensor. The original MAL uses threaded front and back covers, whereas the current MBL replacement utilizes a riveted rolling-packed body. Additionally, the 10 mm carbon-steel rod has 20 um hard chrome plating, supported by a self-lubricating front-cover bearing guide.
Airtac MAL25 Aluminum Alloy Mini Cylinder MAL25X75-U Technical Specifications
| Model | Airtac MAL25 Aluminum Alloy Mini Cylinder MAL25X75-U |
|---|---|
| Series | MAL aluminum-barrel mini round cylinder (discontinued) |
| Replacement | MBL25X75-U |
| Bore size | Ø25 mm |
| Stroke | 75 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MAL datasheet (now discontinued). The MBL25X75-U carries the same ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø25mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 245 N | 206 N |
| 0.7 MPa | 344 N | — |
| Max (@1.0 MPa) | 50 kgf | |
The MBL25X75-U produces the same force from the same bore — a true drop-in on output. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac MAL25 Aluminum Alloy Mini Cylinder MAL25X75-U
| MAL | Aluminum-barrel mini round cylinder, double acting (discontinued). |
|---|---|
| 25 | Bore size in mm (20/25/32/40). |
| ×75 | Stroke length in mm. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBL uses CMSG/DMSG/EMSG). |
| CA / U / CM | Back cover: CA pivot, U flat-end or CM round-end. |
Replacement mapping: MAL → MBL, MSAL → MSBL, MTAL → MTBL, MALD → MBLD, MALJ → MBLJ.
Where the Airtac MAL25 Aluminum Alloy Mini Cylinder MAL25X75-U Is Used
PCB Shuttle Guidance
Moves 75 mm to shuttle bare PCBs between pick-and-place heads using 245 N of push force at 0.5 MPa.
Connector Insertion Jig
Provides 206 N of pull force to seat ribbon connectors into edge modules within a tight electronics assembly fixture.
Carton Flap Folder
Folds secondary carton flaps at 30-800 mm/s in compact end-of-line packaging equipment where space is restricted.
Replacing the Airtac MAL25 Aluminum Alloy Mini Cylinder MAL25X75-U with MBL25X75-U
To replace the MAL25X75-U, order the MBL25X75-U, ensuring you match the PT thread form and U flat-end back cover. If you need position sensing, you must upgrade to an MBL25X75-US, which shifts the sensor family from the legacy CS1-M / DS1-M to the current CMSG / DMSG / EMSG switches. If sizing down, the 20 mm bore provides 157 N push at 0.5 MPa; if stepping up, the 32 mm bore yields 402 N. Note that the fixed rubber bumper softens end-of-stroke impacts but does not lock the rod—if air is lost, the load drifts. For adjustable air cushioning, specify the MBLC series instead.
Upgrade checklist
- ✓ Order the MBL25X75-U (same bore/stroke/force)
- ✓ Same G1/8 port and mounting accessories
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
- ✓ Need a cushion? use MBLC (adjustable air cushion)
- ✓ Confirm back cover (CA / U) and thread (PT/NPT/G)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Front/rear covers are threaded — not intended for field disassembly.
- check Use the correct mounting accessory (LB / FA / SDB) and back cover (CA / U / CM).
- check For new builds, specify the MBL25X75-U instead of this discontinued model.
Airtac MAL25 Aluminum Alloy Mini Cylinder MAL25X75-U FAQ
Yes, the MAL25X75-U is discontinued. The exact drop-in replacement is the MBL25X75-U, offering the same 25 mm bore, 75 mm stroke, G1/8 port, and U flat-end mounting.
At 0.5 MPa, push force is 245 N and pull is 206 N; at 0.7 MPa push is 343 N, with a max theoretical force of 50 kgf at 1.0 MPa. Because this SKU lacks an -S magnet, it cannot take a position sensor.
