This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is MBL32X100-CA — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the MBL32X100-CA in place of this model. The MBL replacement upgrades to a riveted rolling-packed body and the current CMSG / DMSG / EMSG sensor switches (the MAL used CS1-M / DS1-M).
Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X100-CA
The AirTAC Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X100-CA is a double-acting aluminum-barrel mini round cylinder with a Ø32mm bore and 100mm stroke, G1/8 air ports and a fixed rubber bumper. This model is discontinued — the drop-in replacement is the MBL32X100-CA, which matches its bore, stroke, force and mounting.
- BoreØ32 mm
- Stroke100 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- StatusDiscontinued → MBL32X100-CA
About the Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X100-CA
The AirTAC MAL32X100-CA is a discontinued double-acting aluminum mini round cylinder. It delivers 402 N of push force and 346 N of pull force at 0.5 MPa, operating via a 12 mm carbon-steel rod with 20 um hard chrome plating. AirTAC replaced this legacy unit with the MBL32X100-CA, a drop-in upgrade retaining the exact 32 mm bore, 100 mm stroke, G1/8 port, and CA pivot mounting.
This legacy model uses a heterogeneous two-way seal that retains grease, paired with a self-lubricating front-cover bearing guide. The original MAL body features threaded front and back covers, whereas the current MBL replacement uses a riveted rolling-packed body. Because this specific SKU lacks the -S magnet, it cannot support any position sensing. End-stroke energy is absorbed by a fixed rubber bumper, not an adjustable cushion.
Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X100-CA Technical Specifications
| Model | Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X100-CA |
|---|---|
| Series | MAL aluminum-barrel mini round cylinder (discontinued) |
| Replacement | MBL32X100-CA |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MAL datasheet (now discontinued). The MBL32X100-CA carries the same ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
The MBL32X100-CA produces the same force from the same bore — a true drop-in on output. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X100-CA
| MAL | Aluminum-barrel mini round cylinder, double acting (discontinued). |
|---|---|
| 32 | Bore size in mm (20/25/32/40). |
| ×100 | Stroke length in mm. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBL uses CMSG/DMSG/EMSG). |
| CA / U / CM | Back cover: CA pivot, U flat-end or CM round-end. |
Replacement mapping: MAL → MBL, MSAL → MSBL, MTAL → MTBL, MALD → MBLD, MALJ → MBLJ.
Where the Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X100-CA Is Used
Textile Loom Takedown
Actuates the takedown lever on a weaving loom, using the 402 N push force to pull woven fabric down evenly while the CA pivot absorbs the mechanism's arcing rod motion.
Bottling Line Diverter
Pushes a routing gate on a 100 mm stroke to divert glass bottles on a conveyor, where the self-lubricating bearing guide handles high-speed 30-800 mm/s cycling.
Packaging Flap Folder
Folds corrugated cardboard flaps on a case erector, using the fixed rubber bumper to soften the 100 mm end-stroke impact without damaging the packaging material.
Replacing the Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X100-CA with MBL32X100-CA
To replace the MAL32X100-CA, order the MBL32X100-CA. Confirm your 32 mm bore, 100 mm stroke, G1/8 port, and PT threaded connection. The CA back cover provides a pivot clevis that swings on a pin, making it ideal for arcing loads. If you need to step down, the 25 mm bore offers 245 N push at 0.5 MPa; if you need more force, the 40 mm bore provides 628 N push. Note that the MBL upgrade shifts from threaded covers to a riveted body.
Since this unit has no -S magnet, it cannot accept CS1-M or DS1-M sensors. The fixed rubber bumper halts the rod softly but does not lock the load—air loss means the rod drifts, so use an external rod lock for position holding. If your application requires adjustable end-cushioning, step up to the MBLC variant on the current line. With a 100 mm stroke and a 12 mm rod, side-load tolerance is low; rely on the CA pivot to absorb misalignment.
Upgrade checklist
- ✓ Order the MBL32X100-CA (same bore/stroke/force)
- ✓ Same G1/8 port and mounting accessories
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
- ✓ Need a cushion? use MBLC (adjustable air cushion)
- ✓ Confirm back cover (CA / U) and thread (PT/NPT/G)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Front/rear covers are threaded — not intended for field disassembly.
- check Use the correct mounting accessory (LB / FA / SDB) and back cover (CA / U / CM).
- check For new builds, specify the MBL32X100-CA instead of this discontinued model.
Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X100-CA FAQ
Yes, the AirTAC MAL32X100-CA is discontinued. The exact drop-in replacement is the MBL32X100-CA, which matches the 32 mm bore, 100 mm stroke, G1/8 port, and CA pivot mounting. The MBL upgrades the body from threaded covers to a riveted rolling-packed design.
At 0.5 MPa it provides 402 N push and 346 N pull; at 0.7 MPa it provides 563 N push, with a theoretical max of 82 kgf at 1.0 MPa. Because this specific SKU lacks the -S magnet, it cannot accept CS1-M or DS1-M position sensors. The MBL replacement uses the newer CMSG, DMSG, or EMSG sensor family.
