This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is MBL32X100-CM-LB — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the MBL32X100-CM-LB in place of this model. The MBL replacement upgrades to a riveted rolling-packed body and the current CMSG / DMSG / EMSG sensor switches (the MAL used CS1-M / DS1-M).
Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X100-CM-LB
The AirTAC Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X100-CM-LB is a double-acting aluminum-barrel mini round cylinder with a Ø32mm bore and 100mm stroke, G1/8 air ports and a fixed rubber bumper. This model is discontinued — the drop-in replacement is the MBL32X100-CM-LB, which matches its bore, stroke, force and mounting.
- BoreØ32 mm
- Stroke100 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- StatusDiscontinued → MBL32X100-CM-LB
About the Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X100-CM-LB
The AirTAC MAL32X100-CM-LB is a discontinued double-acting aluminum mini round cylinder with a 32mm bore and 100mm stroke. It delivers 402N of push force and 346N of pull force at 0.5MPa, utilizing a Ø12mm carbon-steel rod with 20um hard-chrome plating. The exact drop-in replacement is the MBL32X100-CM-LB, which matches the original bore, stroke, output force, G1/8 port, and LB foot mounting exactly.
This legacy SKU features a CM round-end back cover paired with an LB foot mounting bracket for rigid base mounting. Unlike the older MAL which uses threaded front and back covers on the barrel, the modern MBL replacement features a riveted rolling-packed body for enhanced structural integrity. Note that this specific model lacks the -S magnet option, meaning it cannot support position sensing with CS1-M or DS1-M switches.
Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X100-CM-LB Technical Specifications
| Model | Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X100-CM-LB |
|---|---|
| Series | MAL aluminum-barrel mini round cylinder (discontinued) |
| Replacement | MBL32X100-CM-LB |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MAL datasheet (now discontinued). The MBL32X100-CM-LB carries the same ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
The MBL32X100-CM-LB produces the same force from the same bore — a true drop-in on output. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X100-CM-LB
| MAL | Aluminum-barrel mini round cylinder, double acting (discontinued). |
|---|---|
| 32 | Bore size in mm (20/25/32/40). |
| ×100 | Stroke length in mm. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBL uses CMSG/DMSG/EMSG). |
| CA / U / CM | Back cover: CA pivot, U flat-end or CM round-end. |
Replacement mapping: MAL → MBL, MSAL → MSBL, MTAL → MTBL, MALD → MBLD, MALJ → MBLJ.
Where the Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X100-CM-LB Is Used
Bottle Capping Machine
Provides 402N of push force at 0.5MPa to securely press and torque plastic caps onto beverage containers moving along a high-speed packaging line.
Carton Flap Folder
The 100mm stroke actuates a folding blade to tuck cardboard flaps on a case packing machine, utilizing the LB foot bracket for rigid frame mounting.
Small Part Ejection
Ejects machined aluminum brackets from a CNC milling vise, relying on the fixed rubber bumper to soften the mechanical end-of-stroke impact.
Replacing the Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X100-CM-LB with MBL32X100-CM-LB
To replace the discontinued MAL32X100-CM-LB, order the MBL32X100-CM-LB. Confirm your setup matches the 32mm bore, 100mm stroke, G1/8 port, default PT tapered thread, and LB foot mounting. Because this SKU lacks the -S magnet, it cannot accept a position sensor; if you need end-of-stroke detection, step up to the MBL32X100S-CM-LB and update your switches to the current CMSG, DMSG, or EMSG families. The MAL uses a fixed rubber bumper, so if your application requires adjustable end-cushioning to absorb impact energy, upgrade to the MBLC32X100-CM-LB variant on the current line.
For sizing flexibility, stepping down to the 25mm bore yields 245N push at 0.5MPa, while stepping up to the 40mm bore provides 628N push at 0.5MPa. At 100mm of stroke, the 12mm rod handles moderate extension distances well, but always ensure the LB foot bracket is securely anchored to prevent moment loads. Remember that a standard bumper only softens the end of stroke; it is not a locking mechanism, so the rod will drift if air pressure is lost.
Upgrade checklist
- ✓ Order the MBL32X100-CM-LB (same bore/stroke/force)
- ✓ Same G1/8 port and mounting accessories
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
- ✓ Need a cushion? use MBLC (adjustable air cushion)
- ✓ Confirm back cover (CA / U) and thread (PT/NPT/G)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Front/rear covers are threaded — not intended for field disassembly.
- check Use the correct mounting accessory (LB / FA / SDB) and back cover (CA / U / CM).
- check For new builds, specify the MBL32X100-CM-LB instead of this discontinued model.
Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X100-CM-LB FAQ
Yes, the MAL32X100-CM-LB is discontinued. The exact drop-in replacement is the MBL32X100-CM-LB, which offers the same 32mm bore, 100mm stroke, G1/8 port, CM round-end back cover, and LB foot mounting. The main upgrade is that the MBL uses a riveted rolling-packed body instead of the older threaded covers.
The 32mm bore generates 402N push and 346N pull at 0.5MPa, 563N push at 0.7MPa, and a maximum theoretical force of 82kgf at 1.0MPa. Because this specific SKU does not include the -S magnet, it cannot accept CS1-M or DS1-M position sensors.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
Drop-in Upgrade
The MBL32X100-CM-LB replaces this model 1:1.
Fast Dispatch
MBL replacements usually ship in 3-4 days.
Fast Reply
Most inquiries answered within 7-8 hours.
Recommended AirTAC MBL Replacements
Request a Quote (Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X100-CM-LB → MBL32X100-CM-LB)
Tell us the quantity and destination — we quote the drop-in MBL32X100-CM-LB replacement with price, stock and lead time, usually within 7-8 hours.
