This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is MBL32X75-CA — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the MBL32X75-CA in place of this model. The MBL replacement upgrades to a riveted rolling-packed body and the current CMSG / DMSG / EMSG sensor switches (the MAL used CS1-M / DS1-M).
Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X75-CA
The AirTAC Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X75-CA is a double-acting aluminum-barrel mini round cylinder with a Ø32mm bore and 75mm stroke, G1/8 air ports and a fixed rubber bumper. This model is discontinued — the drop-in replacement is the MBL32X75-CA, which matches its bore, stroke, force and mounting.
- BoreØ32 mm
- Stroke75 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- StatusDiscontinued → MBL32X75-CA
About the Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X75-CA
The AirTAC MAL32X75-CA is a discontinued double-acting aluminum mini round cylinder with a 32mm bore and 75mm stroke. It delivers 402N push and 346N pull at 0.5MPa. The exact drop-in replacement is the MBL32X75-CA, matching the original bore, stroke, force, G1/8 port, and CA pivot mounting.
This legacy unit features threaded front and back covers, whereas the MBL upgrade uses a riveted rolling-packed body. Because this specific SKU lacks an -S magnet, it cannot accept a position sensor. The internal piston relies on a heterogeneous two-way seal that retains grease, paired with a self-lubricating front-cover bearing guide for low-friction rod travel.
Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X75-CA Technical Specifications
| Model | Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X75-CA |
|---|---|
| Series | MAL aluminum-barrel mini round cylinder (discontinued) |
| Replacement | MBL32X75-CA |
| Bore size | Ø32 mm |
| Stroke | 75 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MAL datasheet (now discontinued). The MBL32X75-CA carries the same ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
The MBL32X75-CA produces the same force from the same bore — a true drop-in on output. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X75-CA
| MAL | Aluminum-barrel mini round cylinder, double acting (discontinued). |
|---|---|
| 32 | Bore size in mm (20/25/32/40). |
| ×75 | Stroke length in mm. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBL uses CMSG/DMSG/EMSG). |
| CA / U / CM | Back cover: CA pivot, U flat-end or CM round-end. |
Replacement mapping: MAL → MBL, MSAL → MSBL, MTAL → MTBL, MALD → MBLD, MALJ → MBLJ.
Where the Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X75-CA Is Used
Textile Loom Takedown
Uses the 402N push at 0.5MPa to knock woven fabric rolls off a loom cradle, where the CA pivot absorbs the lateral arc of the swinging arm.
Bottling Line Diverter
Sorts 500ml PET bottles on a 30mm wide guide rail using the 346N pull force, fitting easily into the 32mm compact footprint.
Carton Flap Folder
Folds small corrugated shipping carton flaps at 30-800mm/s, relying on the fixed rubber bumper to soften the 75mm end-of-stroke impact.
Replacing the Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X75-CA with MBL32X75-CA
To replace the MAL32X75-CA, order the MBL32X75-CA. Confirm the PT tapered port thread, the Ø12mm carbon-steel rod with 20µm hard chrome, and the CA pivot back cover, which swings on a pin to absorb arcing loads. Since this SKU has no -S magnet, no sensor is needed; if position detection is required on the new MBL, add the -S option and use CMSG/DMSG/EMSG switches instead of the older CS1-M/DS1-M.
If you need to step down, the 25mm bore neighbor provides 245N push at 0.5MPa. Stepping up to the 40mm bore yields 628N push. The MAL uses a fixed rubber bumper; for adjustable air cushioning, specify the current-line MBLC. Note that a plain cylinder drifts when air is lost, so use an external rod lock for held loads.
Upgrade checklist
- ✓ Order the MBL32X75-CA (same bore/stroke/force)
- ✓ Same G1/8 port and mounting accessories
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
- ✓ Need a cushion? use MBLC (adjustable air cushion)
- ✓ Confirm back cover (CA / U) and thread (PT/NPT/G)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Front/rear covers are threaded — not intended for field disassembly.
- check Use the correct mounting accessory (LB / FA / SDB) and back cover (CA / U / CM).
- check For new builds, specify the MBL32X75-CA instead of this discontinued model.
Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X75-CA FAQ
Yes, the MAL32X75-CA is discontinued. The exact drop-in replacement is the MBL32X75-CA, which matches the 32mm bore, 75mm stroke, G1/8 port, and CA pivot mounting. The MBL upgrades the body to a riveted rolling-packed design instead of the original threaded covers.
The 32mm bore generates 402N push and 346N pull at 0.5MPa, 563N push at 0.7MPa, and a maximum of 82kgf at 1.0MPa. This specific SKU lacks an -S magnet, so it cannot take a position sensor; if you need sensing on the MBL replacement, add the -S option and use CMSG/DMSG/EMSG switches.
