This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is MBL32X75-CA-H — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the MBL32X75-CA-H in place of this model. The MBL replacement upgrades to a riveted rolling-packed body and the current CMSG / DMSG / EMSG sensor switches (the MAL used CS1-M / DS1-M).
Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X75-CA-H
The AirTAC Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X75-CA-H is a double-acting aluminum-barrel mini round cylinder with a Ø32mm bore and 75mm stroke, G1/8 air ports and a fixed rubber bumper. This model is discontinued — the drop-in replacement is the MBL32X75-CA-H, which matches its bore, stroke, force and mounting.
- BoreØ32 mm
- Stroke75 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- StatusDiscontinued → MBL32X75-CA-H
About the Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X75-CA-H
The AirTAC MAL32X75-CA-H is a discontinued double-acting aluminum mini round cylinder. It delivers 402 N of push force and 346 N of pull force at 0.5 MPa. The exact drop-in replacement is the MBL32X75-CA-H, matching the 32 mm bore, 75 mm stroke, G1/8 port, and CA pivot mounting. The legacy MAL body relies on threaded front and back covers, whereas the modern MBL uses a riveted rolling-packed body for equally robust performance.
This specific SKU features a CA pivot back cover, designed to swing on a pin and safely absorb arcing loads throughout the stroke. Because this configuration lacks the -S magnet code, it cannot accept a position sensor. Internally, a heterogeneous two-way seal retains grease against the hard-chrome plated carbon-steel rod, while the self-lubricating front-cover bearing guide maintains smooth travel.
Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X75-CA-H Technical Specifications
| Model | Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X75-CA-H |
|---|---|
| Series | MAL aluminum-barrel mini round cylinder (discontinued) |
| Replacement | MBL32X75-CA-H |
| Bore size | Ø32 mm |
| Stroke | 75 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MAL datasheet (now discontinued). The MBL32X75-CA-H carries the same ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
The MBL32X75-CA-H produces the same force from the same bore — a true drop-in on output. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X75-CA-H
| MAL | Aluminum-barrel mini round cylinder, double acting (discontinued). |
|---|---|
| 32 | Bore size in mm (20/25/32/40). |
| ×75 | Stroke length in mm. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBL uses CMSG/DMSG/EMSG). |
| CA / U / CM | Back cover: CA pivot, U flat-end or CM round-end. |
Replacement mapping: MAL → MBL, MSAL → MSBL, MTAL → MTBL, MALD → MBLD, MALJ → MBLJ.
Where the Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X75-CA-H Is Used
Textile Loom Let-off
Guides yarn tensioning arms with a 402 N push at 0.5 MPa, utilizing the CA pivot bracket to accommodate the swinging arc of the fabric feed mechanism.
Package Divert Arm
Actuates a routing gate on a 75 mm stroke to push parcels between sorting lanes, relying on the self-lubricating bearing to handle rapid 30-800 mm/s cycling.
Bottle Crate Pusher
Shifts filled beverage crates from a palletizer bed, where the 346 N pull force reliably retracts the 12 mm rod despite the inverted load orientation.
Replacing the Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X75-CA-H with MBL32X75-CA-H
To replace the MAL32X75-CA-H, order the MBL32X75-CA-H. It is a true drop-in upgrade: verify your 32 mm bore, 75 mm stroke, G1/8 port, PT thread, and CA clevis pivot. Since this SKU has no -S magnet, you cannot mount a sensor; if position detection is needed, order an MBL32X75S-CA-H and migrate to the current CMSG / DMSG / EMSG switch family (the older CS1-M / DS1-M sensors are retired). If your load drifts when air is lost, note that the fixed rubber bumper is not a lock—you will need an external rod lock.
For sizing flexibility, stepping down to the 25 mm bore yields 245 N push at 0.5 MPa, while stepping up to the 40 mm bore provides 628 N push at 0.5 MPa. If your application requires adjustable end-cushioning to absorb kinetic energy, the fixed bumper on this unit cannot be tuned; instead, specify the MBLC32X75-CA-H from the current catalog.
Upgrade checklist
- ✓ Order the MBL32X75-CA-H (same bore/stroke/force)
- ✓ Same G1/8 port and mounting accessories
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
- ✓ Need a cushion? use MBLC (adjustable air cushion)
- ✓ Confirm back cover (CA / U) and thread (PT/NPT/G)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Front/rear covers are threaded — not intended for field disassembly.
- check Use the correct mounting accessory (LB / FA / SDB) and back cover (CA / U / CM).
- check For new builds, specify the MBL32X75-CA-H instead of this discontinued model.
Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X75-CA-H FAQ
Yes, the MAL series is end-of-life. The exact drop-in replacement is the MBL32X75-CA-H. It matches the 32 mm bore, 75 mm stroke, G1/8 port, and CA pivot mounting. The MBL upgrades the body to a riveted rolling-packed design but retains the same output force and dimensions.
At 0.5 MPa, it provides 402 N push and 346 N pull force. At 0.7 MPa, push increases to 563 N, with a theoretical maximum of 82 kgf at 1.0 MPa. It uses a fixed rubber bumper for end-of-stroke damping; if you need adjustable air cushioning, you must step up to the MBLC equivalent.
