This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is MBL32X80-CA — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the MBL32X80-CA in place of this model. The MBL replacement upgrades to a riveted rolling-packed body and the current CMSG / DMSG / EMSG sensor switches (the MAL used CS1-M / DS1-M).
Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X80-CA
The AirTAC Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X80-CA is a double-acting aluminum-barrel mini round cylinder with a Ø32mm bore and 80mm stroke, G1/8 air ports and a fixed rubber bumper. This model is discontinued — the drop-in replacement is the MBL32X80-CA, which matches its bore, stroke, force and mounting.
- BoreØ32 mm
- Stroke80 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- StatusDiscontinued → MBL32X80-CA
About the Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X80-CA
The AirTAC MAL32X80-CA is a discontinued double-acting aluminum mini round cylinder featuring a 32mm bore and 80mm stroke. It delivers 402N of push force and 346N of pull force at 0.5MPa, utilizing a G1/8 port and a 12mm carbon-steel rod with 20um hard chrome plating. The CA back cover provides a pivot clevis for arcing loads.
The exact drop-in replacement is the MBL32X80-CA, matching the bore, stroke, output force, port, and mounting. The legacy MAL uses threaded front and back covers, while the MBL upgrade features a riveted rolling-packed body. Because this specific SKU lacks the -S magnet, it cannot accept a position sensor; if sensing is needed on the new MBL, order an -S model which uses modern CMSG/DMSG/EMSG switches instead of the older CS1-M/DS1-M.
Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X80-CA Technical Specifications
| Model | Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X80-CA |
|---|---|
| Series | MAL aluminum-barrel mini round cylinder (discontinued) |
| Replacement | MBL32X80-CA |
| Bore size | Ø32 mm |
| Stroke | 80 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MAL datasheet (now discontinued). The MBL32X80-CA carries the same ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
The MBL32X80-CA produces the same force from the same bore — a true drop-in on output. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X80-CA
| MAL | Aluminum-barrel mini round cylinder, double acting (discontinued). |
|---|---|
| 32 | Bore size in mm (20/25/32/40). |
| ×80 | Stroke length in mm. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBL uses CMSG/DMSG/EMSG). |
| CA / U / CM | Back cover: CA pivot, U flat-end or CM round-end. |
Replacement mapping: MAL → MBL, MSAL → MSBL, MTAL → MTBL, MALD → MBLD, MALJ → MBLJ.
Where the Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X80-CA Is Used
Textile Loom Weft Guide
Drives the weft guide mechanism on a textile loom, using the 402N push force at 0.5MPa to positively position the yarn carrier across the 80mm stroke.
Packaging Flap Folder
Folds cardboard end flaps on a small carton sealing machine, where the CA pivot clevis absorbs the slight angular misalignment as the 32mm rod retracts.
Bottle Sorting Chute Diverter
Actuates a diverter gate on a bottle sorting chute, relying on the self-lubricating front-cover bearing to maintain smooth operation in a dusty packaging environment.
Replacing the Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X80-CA with MBL32X80-CA
To replace the MAL32X80-CA, order the MBL32X80-CA to retain the 32mm bore, 80mm stroke, G1/8 port, PT thread, and CA pivot back cover. If your application requires an adjustable air cushion at the end of stroke—which the fixed rubber bumper on this MAL lacks—step up to the MBLC32X80-CA on the current line. If sizing down for a lighter load, the 25mm bore neighbor offers 245N push at 0.5MPa; if stepping up for heavier forces, the 40mm bore provides 628N push at 0.5MPa. Note that a plain bumper only softens end-of-stroke impact and does not lock the load; if air is lost, the rod drifts, requiring an external rod lock or pilot-operated check valve to hold position.
Upgrade checklist
- ✓ Order the MBL32X80-CA (same bore/stroke/force)
- ✓ Same G1/8 port and mounting accessories
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
- ✓ Need a cushion? use MBLC (adjustable air cushion)
- ✓ Confirm back cover (CA / U) and thread (PT/NPT/G)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Front/rear covers are threaded — not intended for field disassembly.
- check Use the correct mounting accessory (LB / FA / SDB) and back cover (CA / U / CM).
- check For new builds, specify the MBL32X80-CA instead of this discontinued model.
Airtac MAL32 Aluminum Alloy Mini Air Cylinder MAL32X80-CA FAQ
Yes, the MAL32X80-CA is discontinued. The exact drop-in replacement is the MBL32X80-CA, which matches the 32mm bore, 80mm stroke, 402N push force at 0.5MPa, G1/8 port, and CA pivot mounting. You must order the MBL32X80-CA for an exact physical swap.
At 0.5MPa, the 32mm bore provides 402N push and 346N pull force. At 0.7MPa, the push force is 563N, with a maximum theoretical force of 82kgf at 1.0MPa. Because this specific SKU lacks the -S magnet, it cannot accept a position sensor; the MBL replacement with an -S suffix is required to use CMSG/DMSG/EMSG switches.
