Airtac MARF Stainless Steel Mini Air Cylinder MARF20X15S
The AirTAC Airtac MARF Stainless Steel Mini Air Cylinder MARF20X15S is a genuine double acting + cushion (front mount) standard round-body mini air cylinder with a Ø20mm bore and 15mm stroke, 1/8" air ports and a stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service. A variable air cushion at both ends lets you tune end-of-stroke deceleration on site.
- BoreØ20 mm
- Stroke15 mm
- Port size1/8"
- Acting typeDouble acting + cushion (front mount)
- Rod threadM8×1.25
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MARF Stainless Steel Mini Air Cylinder MARF20X15S
With just 15 mm of travel, the MARF20X15S is a compact front-flange actuator for tight clamps and short, positive pushes. The 20 mm double-acting piston develops 157.0 N at 0.5 MPa (131.9 N on retract), with a variable cushion at each end to absorb the last fraction of the throw.
Its riveted stainless tube and hard-chrome 8 mm rod handle washdown better than painted minis, and the two-way piston seal retains grease for long, dry-running intervals. At 0.5 MPa the 157.0 N push translates to about 8 kg of vertical lift with a 2:1 margin, enough for small fixture lids and covers. On air loss the piston simply drifts, so add a rod lock where the clamp must stay closed. The magnet is built in as standard, ready for CMSG, DMSG or EMSG switches.
Airtac MARF Stainless Steel Mini Air Cylinder MARF20X15S Technical Specifications
| Model | Airtac MARF Stainless Steel Mini Air Cylinder MARF20X15S |
|---|---|
| Series | MAR mini cylinder |
| Bore size | Ø20 mm |
| Stroke | 15 mm |
| Acting type | Double acting + cushion (front mount) |
| Port size | 1/8" |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MA-series datasheet. Barrel: stainless-steel tube (round-body, riveted rolling-packed construction); piston rod: carbon steel with 20µm hard-chrome plating; covers: aluminium alloy. Thread options: PT (blank) / G / NPT. Every MA-series cylinder ships with a built-in magnet for CMSG / DMSG / EMSG position sensors.
Theoretical Output Force (Ø20mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 157 N | 132 N |
| 0.7 MPa | 220 N | 185 N |
| Max (@1.0 MPa) | 32 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MARF Stainless Steel Mini Air Cylinder MARF20X15S
| MAR | Standard round-body mini cylinder (double-acting, integrated mount, variable cushion). |
|---|---|
| F | Front-cover mount: F = front-flange mounting. |
| 20 | Bore size in mm. |
| ×15 | Stroke length in mm. |
| -S | Built-in magnet for CMSG / DMSG / EMSG sensors (standard on MA series). |
MA-family variants: MA / MAC (double acting ±cushion), MSA / MTA (single acting push / pull), MAD / MACD (double rod ±cushion), MAJ / MACJ (adjustable stroke ±cushion), MAR (cushioned with integrated F/U mount). Mounting accessories: FA flange, LB foot, SDB pivot; plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MARF Stainless Steel Mini Air Cylinder MARF20X15S Is Used
Pin ejector
Kicks finished dowel pins clear of a small drilling fixture with a crisp 15 mm throw and cushioned return.
PCB test clamp
Clamps a controller board into a bed-of-nails tester; the short stroke opens and closes the fixture lid in milliseconds.
Indexing pawl
Advances a pawl on a rotary indexing table where only a short, firm, repeatable move is required each cycle.
Is the Airtac MARF Stainless Steel Mini Air Cylinder MARF20X15S the Right Cylinder?
Fifteen millimetres of travel makes this a force decision, not a stroke decision: at 0.5 MPa bore 20 delivers 157.0 N while bore 25 reaches 245.3 N, so oversize if the tooling pushes back. A CMSG or DMSG switch drops straight onto the barrel for clamp-open signals since the magnet is standard. The I and Y rod knuckles thread onto the M8x1.25 rod and the 1/8 inch ports take standard fittings; operating range is 0.15-1.0 MPa (22-145 psi) at 30-800 mm/s.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) is standard for sensors
- ✓ Back cover (CA/U/CM) & mount (FA/LB/SDB)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion screws and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MARF Stainless Steel Mini Air Cylinder MARF20X15S FAQ
Push is 157.0 N at 0.5 MPa and 219.8 N at 0.7 MPa, while pull reads 131.9 N and 184.7 N at those same pressures. Maximum theoretical output is 32 kgf at 1.0 MPa. Bore is 20 mm, rod is 8 mm, and the port is 1/8 inch.
The 20 mm barrel is stainless steel with aluminium-alloy covers rolled on, and the 8 mm rod is hard-chrome plated to about 20 um, so the MARF20X15S copes far better with damp, washdown or outdoor duty than painted mini cylinders.
