Airtac MARU Stainless Steel Mini Cylinder MARU20X10S
2. Features asymmetrical bidirectional piston seal configuration with compact dimensions and integrated oil reservoir functionality;
3. Integrated cushioning pads on both end caps mitigate impact during directional changes;
4. Multiple rear cover configurations facilitate flexible mounting solutions;
5. Riveted composite enclosure structure ensures reliable connection between end caps and stainless steel barrel;
6. Precision-engineered stainless steel tubing barrel demonstrates exceptional mechanical strength and superior corrosion resistance;
7. Comprehensive options including multiple bore sizes and mounting accessories available for customized applications;
8. Full magnetic circuit pre-installed across all series models.
Category: Stainless Steel Miniature Cylinders | Brand: AIRTAC | Series: MARU
AirTAC MARU Stainless Steel Mini Cylinder MARU20X10S Technical Details
- Model: MARU20X10S (Stainless Steel Series)
- Bore size: 20mm
- Stroke: 10mm (Customizable up to 100mm)
- Operation type: Double-acting
- Working pressure: 0.05–1.0 MPa
- Ambient temperature: -20℃ to 80℃ (Dry air required below 0℃)
- Cushioning: Adjustable rubber bumper (Both ends)
- Port size: M5×0.8 (Standard) or NPT1/8 (Optional)
- Piston rod material: SUS304 stainless steel
- Seal material: Heat-resistant NBR + Fluororubber (FKM) combination
- Body finish: Mirror polishing (Ra ≤0.2μm)
- Weight: 0.27kg ±5% (Without accessories)
- Dimensions: 60mm(L) × 32mm(W) × 32mm(H) (Cylinder body only)
- Mounting options: Basic type (No built-in mounts) with optional flange/bracket kits
- ISO standard: Compliant with ISO 6432 (Mounting dimensions)
Ultra-compact corrosion-resistant cylinder engineered for precision motion in harsh environments. Features full stainless steel construction with dual-layer sealing system, providing exceptional resistance to chemicals, high humidity, and particulate contamination. The through-rod design allows easy position detection integration. Requires 5μm filtered air with lubrication (ISO VG32 recommended).
- Cleanroom semiconductor handling equipment
- Pharmaceutical capsule filling machines
- Marine robotics actuator systems
- Food-grade packaging lines (NSF compliant)
- High-cycle laboratory automation (Up to 1,200 CPM)
Installation tip:
Apply anti-seize compound on threaded ports when using in saltwater environments.
Maximum side load: 2.5N at full extension. Lubricate every 500km of cumulative travel.
| Property | Property Value |
|---|---|
| sku | MARU20X10S |
| Front Cover Type | Upper Fixed Type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
