Airtac MBLCD Aluminum Alloy Mini Cylinder MBLCD20X20
2. Riveted aluminum clamshell structure integrates front/rear end caps with aluminum alloy barrel for enhanced connection reliability;
3. Custom-profiled bidirectional piston sealing system delivers compact dimensions with integrated oil reservoir functionality;
4. Multiple rear cover configurations facilitate flexible installation options;
5. Comprehensive range of cylinder specifications and mounting accessories available for diverse industrial applications.
Category: Aluminum Miniature Cylinders | Brand: AirTAC | Series: MBLCD Series
AirTAC MBLCD20X20 Aluminum Miniature Cylinder Specifications
- Model: MBLCD20X20
- Type: Double-acting compact cylinder
- Bore size: 20mm
- Stroke: 20mm (customizable 5-100mm)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable rubber buffer + shock absorber pad
- Mounting style: Basic type (optional foot/rod flange)
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Piston material: Aluminum alloy with hard anodized surface
- Rod material: Stainless steel SUS304
- Seal type: NBR seals (FKM available for high temp)
- Temperature range: -20℃ to 80℃ (extended to 120℃ with FKM seals)
- Weight: 0.25kg (bare cylinder), 0.32kg with accessories
- Dimensions: 78mm(L) × 20mm(Bore) × 34mm(Mounting height)
- Stroke tolerance: ±1.5mm
- Max speed: 500mm/s
- Lubrication: Non-lube or ISO VG32 turbine oil
Ultra-compact cylinder optimized for space-constrained automation, featuring a 45% weight reduction compared to standard models. Precision-machined guide grooves enable direct sensor mounting. Anti-rotation design maintains orientation stability during high-frequency cycles (up to 5Hz).
- PCB handling robots in electronics assembly
- Micro-dosing valves in pharmaceutical equipment
- Lens positioning systems for optical instruments
- Quick-clamp mechanisms in semiconductor wafer processing
- Veterinary dental chair adjustments
Installation protocol:
Use torque-controlled tightening (1.2-1.5N·m for M5 screws). Maintain 0.5mm alignment tolerance between rod and load. For vertical mounting, install exhaust mist separator to prevent lubrication washout.
| Property | Property Value |
|---|---|
| sku | MBLCD20X20 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <20mm> |
| Stroke | <20mm> |
