Airtac MBLCD Aluminum Alloy Mini Cylinder MBLCD20X200S
$43.49
Regular price
$50.99
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MBLCD20X200S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with AirTAC corporate standards, featuring precision-engineered aluminum round tube barrel construction;
2. Riveted aluminum clamshell structure integrates front/rear end caps with aluminum alloy barrel for enhanced connection reliability;
3. Custom-profiled bidirectional piston sealing system delivers compact dimensions with integrated oil reservoir functionality;
4. Multiple rear cover configurations facilitate flexible installation options;
5. Comprehensive range of cylinder specifications and mounting accessories available for diverse industrial applications.
Category: Aluminum Miniature Cylinders | Brand: AirTAC | Series: MBLCD Series
Installation notes:
(1) Lubricate with ISO VG32 hydraulic oil before initial use.
(2) Avoid side load exceeding 5N·m.
(3) For vertical mounting, install with rod end downward to prevent debris accumulation.
(4) Max speed ≤1000mm/s with full cushion engagement.
2. Riveted aluminum clamshell structure integrates front/rear end caps with aluminum alloy barrel for enhanced connection reliability;
3. Custom-profiled bidirectional piston sealing system delivers compact dimensions with integrated oil reservoir functionality;
4. Multiple rear cover configurations facilitate flexible installation options;
5. Comprehensive range of cylinder specifications and mounting accessories available for diverse industrial applications.
Category: Aluminum Miniature Cylinders | Brand: AirTAC | Series: MBLCD Series
AirTAC MBLCD Aluminum Miniature Cylinder MBLCD20X200S Specifications
- Model: MBLCD20X200S
- Type: Double-acting compact cylinder with magnetic piston
- Bore size: 20mm
- Stroke: 200mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable elastic cushion (both ends)
- Port size: M5x0.8 (standard), optional NPT1/8
- Piston material: Aluminum alloy with hard anodized surface
- Rod material: Stainless steel (SUS304)
- Seal type: NBR rubber seals
- Temperature range: -20℃ to 80℃
- Mounting style: Basic type (accessory brackets available)
- Weight: 680g ±3%
- Dimensions: 275mm(L) × 28mm(W) × 28mm(H)
- Max theoretical thrust: 31.4kgf @0.5MPa
- Repeat positioning accuracy: ±0.5mm
Ultra-slim aluminum cylinder optimized for space-constrained automation systems. Features wear-resistant chromium-plated rod and dual anti-rotation design for precise linear motion. Integrated magnet enables position feedback when paired with magnetic sensors (sensors sold separately).
Typical Applications:
- PCB handling robots in electronics assembly
- Precision clamping mechanisms in CNC tool changers
- Label application arms in packaging lines
- Micro-positioning stages in optical equipment
- Cleanroom medical device actuators
Installation notes:
(1) Lubricate with ISO VG32 hydraulic oil before initial use.
(2) Avoid side load exceeding 5N·m.
(3) For vertical mounting, install with rod end downward to prevent debris accumulation.
(4) Max speed ≤1000mm/s with full cushion engagement.
| Property | Property Value |
|---|---|
| sku | MBLCD20X200S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <20mm> |
| Stroke | <200mm> |
