Airtac MDD Multi-position Double Rod Cylinder MDD16X30
2. Features multiple mounting configurations for simplified installation;
3. Supports ganged mounting of multiple cylinders, optimizing space utilization;
4. High-precision rod guidance ensures maintenance-free operation without external lubrication;
5. Available in multiple bore sizes and stroke lengths for flexible application requirements;
6. Optional high-temperature resistant seals enable reliable performance at 150°C operating conditions. (Optional)
Category: Multi-Position Fixed Cylinders , Brand: AirTAC , Series: MDD
AirTAC MDD Series Multi-Position Dual-Rod Cylinder MDD16X30 Technical Details
- Model: MDD16X30
- Bore size: Ø16mm
- Stroke: 30mm (adjustable)
- Operating pressure: 0.05–0.9 MPa
- Piston rod diameter: Ø6mm (dual rods)
- Max thrust: 18.1kgf at 0.6MPa
- Ambient temperature: -10℃ to 80℃
- Buffer type: Adjustable rubber cushion
- Mounting style: Standard MF1 front flange
- Weight: 0.54kg ±3%
- Dimensions:
- Total length: 158mm (at mid-stroke)
- Body width: 43mm
- Height with rods: 60mm
- Mounting hole spacing: 30mm × 30mm
- Seal material: NBR + PU combination
- Position detection: Optional magnetic piston (MDD16X30-M9 available)
- Repeat positioning accuracy: ±0.2mm
Precision dual-rod cylinder with enhanced lateral load capacity and position stability. Features symmetrical force transmission through parallel rods, ideal for applications requiring multi-point positioning or anti-rotation. Chrome-plated rods with integrated scrapers prevent particulate contamination.
- CNC tool changers requiring dual-axis alignment
- Semiconductor wafer handling robots
- Precision clamping fixtures in injection molding
- Automated optical inspection (AOI) positioning stages
- Pharmaceutical tablet pressing mechanisms
Installation tip:
For vertical installations exceeding 45° angle, use rod-end support brackets (ASF16 accessory recommended).
Lubricate with ISO VG32 hydraulic oil during initial setup.
| Property | Property Value |
|---|---|
| sku | MDD16X30 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 30mm |
