Airtac MF20-25 Stainless Steel Mini Cylinder MF20X100SCMLB
$36.25
Regular price
$43.75
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MF20X100SCMLB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MF20~25 Stainless Steel Miniature Cylinder Series (AIRTAC)
Category: Stainless Steel Miniature Cylinders | Brand: AIRTAC | Series: MF20~25
1. Compliant with JIS industrial standards;
2. Features profiled bidirectional piston sealing with compact dimensions and integrated oil retention structure;
3. Fixed cushioning pads on front/rear covers minimize directional switching impact;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped roller-clad bonding between stainless steel barrel and end covers ensures robust connectivity;
6. High-precision stainless steel barrel delivers superior strength and corrosion resistance;
7. Compact design: MF series achieves shorter overall length compared to ISO 6432 standard cylinders with equivalent bore/stroke;
8. Comprehensive product range with optional mounting accessories for diversified applications.
*Engineered for precision motion control in corrosive or space-constrained environments.*
Installation note:
For optimal performance, maintain 0.5-1mm alignment tolerance during mounting.
Lubricate piston rod weekly in high-cycle applications (>500,000 cycles/month).
Avoid side loads exceeding 15N.
2. Features profiled bidirectional piston sealing with compact dimensions and integrated oil retention structure;
3. Fixed cushioning pads on front/rear covers minimize directional switching impact;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped roller-clad bonding between stainless steel barrel and end covers ensures robust connectivity;
6. High-precision stainless steel barrel delivers superior strength and corrosion resistance;
7. Compact design: MF series achieves shorter overall length compared to ISO 6432 standard cylinders with equivalent bore/stroke;
8. Comprehensive product range with optional mounting accessories for diversified applications.
*Engineered for precision motion control in corrosive or space-constrained environments.*
AirTAC MF20X100SCMLB Stainless Steel Mini Cylinder Specifications
- Model: MF20X100SCMLB
- Series: MF20~25 stainless steel series
- Bore size: 20 mm
- Stroke: 100 mm
- Operation type: Double-acting
- Material: Stainless steel (SUS304 barrel, hardened piston rod)
- Mounting style: Front flange & rear threaded (M5x0.8)
- Cushioning: Adjustable rubber buffer
- Operating pressure: 0.05–1.0 MPa
- Max. piston speed: 500 mm/s
- Temperature range: -20℃ to 150℃
- Seal material: Heat-resistant NBR (optional FKM for chemical resistance)
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Weight: 320 g ±5%
- Dimensions: 150mm(L) × 28mm(W) × 28mm(H) (retracted state)
- Rod end: Female thread M5x0.8
- Built-in magnet: Yes (for magnetic sensor attachment)
- Protection rating: IP67
Precision-engineered stainless steel mini cylinder with corrosion-resistant construction, designed for harsh environments requiring frequent sterilization or chemical exposure. Features laser-engraved identification marks and low-friction seals for smooth operation. Requires 5-40μm filtered compressed air with ISO VG32 lubricator oil (optional oil-free operation).
Typical Applications:
- Cleanroom automation in semiconductor manufacturing
- Precision positioning in medical diagnostic equipment
- Food packaging machinery with frequent washdown requirements
- Pharmaceutical tablet press ejection systems
- High-temperature oven door mechanisms
Installation note:
For optimal performance, maintain 0.5-1mm alignment tolerance during mounting.
Lubricate piston rod weekly in high-cycle applications (>500,000 cycles/month).
Avoid side loads exceeding 15N.
Sensor Compatibility:
Works with all major brand magnetic sensors (e.g., SMC D-M9N, Festool SME-8)
with 1.5-2.5mm detection distance. Sensor groove width: 6mm.
| Property | Property Value |
|---|---|
| sku | MF20X100SCMLB |
| Rear Cover Type | Round Type |
| Mounting Type | Axial Mounting Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
