Airtac MF20-25 Stainless Steel Mini Cylinder MF20X100SCMTC
$40.44
Regular price
$47.94
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MF20X100SCMTC
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MF20~25 Stainless Steel Miniature Cylinder Series (AIRTAC)
Category: Stainless Steel Miniature Cylinders | Brand: AIRTAC | Series: MF20~25
1. Compliant with JIS industrial standards;
2. Features profiled bidirectional piston sealing with compact dimensions and integrated oil retention structure;
3. Fixed cushioning pads on front/rear covers minimize directional switching impact;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped roller-clad bonding between stainless steel barrel and end covers ensures robust connectivity;
6. High-precision stainless steel barrel delivers superior strength and corrosion resistance;
7. Compact design: MF series achieves shorter overall length compared to ISO 6432 standard cylinders with equivalent bore/stroke;
8. Comprehensive product range with optional mounting accessories for diversified applications.
*Engineered for precision motion control in corrosive or space-constrained environments.*
Installation note:
Ensure rod alignment within 0.2mm lateral tolerance. Use PTFE lubricant
for high-cycle applications (>500k cycles). Replace buffer seals every
2 million strokes in continuous operation.
2. Features profiled bidirectional piston sealing with compact dimensions and integrated oil retention structure;
3. Fixed cushioning pads on front/rear covers minimize directional switching impact;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped roller-clad bonding between stainless steel barrel and end covers ensures robust connectivity;
6. High-precision stainless steel barrel delivers superior strength and corrosion resistance;
7. Compact design: MF series achieves shorter overall length compared to ISO 6432 standard cylinders with equivalent bore/stroke;
8. Comprehensive product range with optional mounting accessories for diversified applications.
*Engineered for precision motion control in corrosive or space-constrained environments.*
AirTAC MF20X100SCMTC Stainless Steel Mini Cylinder Specifications
- Series: MF20~25 stainless steel series
- Bore size: 20mm
- Stroke: 100mm
- Material: SUS304 stainless steel (rod/chamber)
- Operating pressure: 0.15-1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Cushion type: Rubber buffer (both ends)
- Mounting style: Multi-position (basic, front flange, rear flange)
- Piston speed: 50-700mm/s (recommended)
- Lubrication: Pre-lubricated (NBR seals)
- Protection rating: IP65 (standard)
- Weight: 450g ±3% (without accessories)
- Dimensions: 142mm(L) × 40mm(W) × 40mm(H)
Corrosion-resistant compact actuator with precision ground rod (Ra≤0.4μm surface roughness). Features magnetic piston for sensor compatibility and double O-ring seals. Requires 5μm filtered air (ISO 8573-1:2010 class 4).
Typical Applications:
- Food processing machinery (washdown environments)
- Medical device positioning systems
- Semiconductor wafer handling robots
- Pharmaceutical blister packaging
- Cleanroom automation equipment
Installation note:
Ensure rod alignment within 0.2mm lateral tolerance. Use PTFE lubricant
for high-cycle applications (>500k cycles). Replace buffer seals every
2 million strokes in continuous operation.
| Property | Property Value |
|---|---|
| sku | MF20X100SCMTC |
| Rear Cover Type | Round Type |
| Mounting Type | Center Pivot Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
