Airtac MF20-25 Stainless Steel Mini Cylinder MF20X10SCMLB
$32.53
Regular price
$40.03
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MF20X10SCMLB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MF20~25 Stainless Steel Miniature Cylinder Series (AIRTAC)
Category: Stainless Steel Miniature Cylinders | Brand: AIRTAC | Series: MF20~25
1. Compliant with JIS industrial standards;
2. Features profiled bidirectional piston sealing with compact dimensions and integrated oil retention structure;
3. Fixed cushioning pads on front/rear covers minimize directional switching impact;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped roller-clad bonding between stainless steel barrel and end covers ensures robust connectivity;
6. High-precision stainless steel barrel delivers superior strength and corrosion resistance;
7. Compact design: MF series achieves shorter overall length compared to ISO 6432 standard cylinders with equivalent bore/stroke;
8. Comprehensive product range with optional mounting accessories for diversified applications.
*Engineered for precision motion control in corrosive or space-constrained environments.*
Installation guidelines:
Use stainless steel compatible grease (No. 2 lithium complex recommended).
Maintain 0.5mm minimum clearance between magnetic sensor and cylinder body.
For vertical mounting, install rod-end down to prevent moisture accumulation.
2. Features profiled bidirectional piston sealing with compact dimensions and integrated oil retention structure;
3. Fixed cushioning pads on front/rear covers minimize directional switching impact;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped roller-clad bonding between stainless steel barrel and end covers ensures robust connectivity;
6. High-precision stainless steel barrel delivers superior strength and corrosion resistance;
7. Compact design: MF series achieves shorter overall length compared to ISO 6432 standard cylinders with equivalent bore/stroke;
8. Comprehensive product range with optional mounting accessories for diversified applications.
*Engineered for precision motion control in corrosive or space-constrained environments.*
AirTAC MF20X10SCMLB Stainless Steel Mini Cylinder Specifications
- Series: MF20~25 Stainless Steel Mini Series
- Full model: MF20X10SCMLB
- Bore size: 20mm (MF20)
- Stroke: 10mm
- Material: Stainless Steel 316 (Body/Rod)
- Operation type: Double-acting
- Operating pressure: 0.1-0.8 MPa
- Temperature range: -20℃ ~ 150℃
- Cushioning: Adjustable rubber buffer
- Port size: M5x0.8 (Rc1/8 adapter optional)
- Rod thread: M6x1.0
- Seal material: Heat-resistant NBR + Fluororubber (FKM) hybrid
- Mounting type: Front flange (NFAB style)
- Weight: 0.34kg (without accessories)
- Dimensions:
- Length: 53mm (compact build-up length)
- Width: 32mm (flange mounting base)
- Height: 28mm (body diameter)
- Accessories: Built-in magnet for magnetic sensor (SM/SMC series compatible)
- ISO standard: Compliant with ISO 6432
Ultra-compact corrosion-resistant cylinder with 70% reduced size compared to standard models. Features laser-engraved stroke markers and dual-purpose mounting slots. The polished rod surface (Ra≤0.4μm) minimizes seal wear. Rated for 5,000km service life under standard conditions (0.3MPa, 20℃).
Ideal Applications:
- Cleanroom semiconductor handling robots
- Sterile medical device actuators
- High-cycle food packaging machines
- Marine equipment controls
- Pharmaceutical tablet press mechanisms
Installation guidelines:
Use stainless steel compatible grease (No. 2 lithium complex recommended).
Maintain 0.5mm minimum clearance between magnetic sensor and cylinder body.
For vertical mounting, install rod-end down to prevent moisture accumulation.
| Property | Property Value |
|---|---|
| sku | MF20X10SCMLB |
| Rear Cover Type | Round Type |
| Mounting Type | Axial Mounting Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
