Airtac MF32-40 Stainless Steel Mini Cylinder MF32X100CAH
1. Complies with JIS (Japanese Industrial Standards) specifications;
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. Fixed cushioning pads on both end caps minimize directional reversal impact;
4. Multiple rear cover configurations enhance mounting flexibility;
5. Riveted roller-clamped connection ensures secure and durable body connection between stainless steel barrel and end caps;
6. High-precision stainless steel tubing construction delivers exceptional strength and superior corrosion resistance;
7. Compact profile design: MF series achieves shorter overall length than ISO 6432 standard cylinders with equivalent bore size and stroke;
8. Comprehensive range of cylinder specifications and mounting accessories provides customizable solutions.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MF32~40
AirTAC MF32X100CAH Stainless Steel Mini Cylinder Specifications
- Model: MF32X100CAH (MF32~40 series)
- Bore size: 32 mm
- Stroke: 100 mm
- Action type: Double-acting
- Material: Stainless steel (SUS304 body, NBR seals)
- Operating pressure: 0.05~1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: M5×0.8 (G1/8 optional)
- Piston speed: 50~700 mm/s
- Mounting type: Basic foot mounting (CAH series)
- Weight: 1.25 kg ±3%
- Dimensions:
- Extended length: 195 mm
- Retracted length: 95 mm
- Body width: 40 mm
- Mounting hole spacing: 25×25 mm
- Protection rating: IP65 (standard wiper design)
- Lubrication: Pre-lubricated (oil-free operation possible)
Compact stainless steel cylinder with corrosion-resistant construction, designed for precision linear motion in harsh environments. Features dual adjustable air cushions for smooth end-of-stroke deceleration and reduced impact noise. The CAH variant includes reinforced mounting lugs for improved stability in high-vibration applications.
- Food processing machinery (washdown environments)
- Pharmaceutical production lines
- Semiconductor manufacturing equipment
- Marine automation systems
- High-cycle packaging machines (500+ cycles/minute)
Installation note:
For vertical mounting, reduce maximum load capacity by 30%. Use locknuts with 1.5Nm torque on mounting bolts.
Lubricate rod with ISO VG32 hydraulic oil if operating below -10℃.
| Property | Property Value |
|---|---|
| sku | MF32X100CAH |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
