Airtac MF32-40 Stainless Steel Mini Cylinder MF32X100SCM
1. Complies with JIS (Japanese Industrial Standards) specifications;
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. Fixed cushioning pads on both end caps minimize directional reversal impact;
4. Multiple rear cover configurations enhance mounting flexibility;
5. Riveted roller-clamped connection ensures secure and durable body connection between stainless steel barrel and end caps;
6. High-precision stainless steel tubing construction delivers exceptional strength and superior corrosion resistance;
7. Compact profile design: MF series achieves shorter overall length than ISO 6432 standard cylinders with equivalent bore size and stroke;
8. Comprehensive range of cylinder specifications and mounting accessories provides customizable solutions.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MF32~40
AirTAC MF32X100SCM Stainless Steel Mini Cylinder Specifications
- Series: MF32~40 Compact Series
- Model: MF32X100SCM
- Bore size: 32mm
- Stroke: 100mm
- Material: Stainless steel (SUS304 barrel, CR rod)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 150℃
- Port size: M5x0.8 (standard), optional NPT1/8
- Cushioning: Fixed buffer with adjustable end caps
- Mounting types: Basic type (MF32) + Foot mounting (optional)
- Weight: 680g ±2%
- Dimensions:
- Length: 176mm (fully retracted)
- Width: 45mm (max body width)
- Height: 45mm (including mounting protrusions)
- Rod thread: M10x1.25 (external)
- Max theoretical thrust: 226N at 0.7MPa
- ISO standard: 6432 compliant
Ultra-compact stainless steel cylinder with full-body corrosion resistance, designed for harsh environments requiring frequent washdowns or chemical exposure. Features precision honed inner tube (Ra≤0.2μm) and double-sealed rod gland for leak prevention. Optional auto switch grooves (M5 mounting) for position sensing.
- Food processing machinery actuators
- Pharmaceutical cleanroom automation
- Semiconductor wafer handling systems
- Marine equipment controls
- High-temperature oven door mechanisms
Installation note:
Apply silicone-free lubricant (ISO VG32) during assembly.
For vertical mounting, use auxiliary rod support when stroke exceeds 80mm.
Maximum side load capacity: 15N at rod end.
| Property | Property Value |
|---|---|
| sku | MF32X100SCM |
| Rear Cover Type | Round Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
