Airtac MF32-40 Stainless Steel Mini Cylinder MF40X40CAH
$53.47
Regular price
$60.97
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MF40X40CAH
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MF32~40 Stainless Steel Mini Cylinder Series
1. Complies with JIS (Japanese Industrial Standards) specifications;
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. Fixed cushioning pads on both end caps minimize directional reversal impact;
4. Multiple rear cover configurations enhance mounting flexibility;
5. Riveted roller-clamped connection ensures secure and durable body connection between stainless steel barrel and end caps;
6. High-precision stainless steel tubing construction delivers exceptional strength and superior corrosion resistance;
7. Compact profile design: MF series achieves shorter overall length than ISO 6432 standard cylinders with equivalent bore size and stroke;
8. Comprehensive range of cylinder specifications and mounting accessories provides customizable solutions.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MF32~40
Maintenance tip:
Relubricate every 3,000 km operation using ISO VG32 hydraulic oil.
Avoid side load exceeding 10N·m. For vertical mounting,
use optional guide bracket (model MFL40-10).
1. Complies with JIS (Japanese Industrial Standards) specifications;
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. Fixed cushioning pads on both end caps minimize directional reversal impact;
4. Multiple rear cover configurations enhance mounting flexibility;
5. Riveted roller-clamped connection ensures secure and durable body connection between stainless steel barrel and end caps;
6. High-precision stainless steel tubing construction delivers exceptional strength and superior corrosion resistance;
7. Compact profile design: MF series achieves shorter overall length than ISO 6432 standard cylinders with equivalent bore size and stroke;
8. Comprehensive range of cylinder specifications and mounting accessories provides customizable solutions.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MF32~40
AirTAC MF40X40CAH Stainless Steel Mini Cylinder Technical Details
- Model Series: MF32~40 Compact Series
- Full Model: MF40X40CAH
- Bore size: 40mm
- Stroke: 40mm
- Material: SUS304 stainless steel (body), NBR seals
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 150℃
- Port size: M5x0.8 (standard), optional G1/8
- Cushion type: Adjustable pneumatic cushion (both ends)
- Mounting style: Front flange with through holes
- Protection rating: IP67 (standard wiper included)
- Lubrication: Pre-lubricated (optional grease-free version)
- Max piston speed: 500 mm/s
- Repeat positioning accuracy: ±0.5mm
- Service life: 5,000 km (under standard conditions)
- Weight: 0.85 kg (excluding accessories)
- Dimensions: 163mm(L) × 40mm(W) × 40mm(H) (fully retracted)
Corrosion-resistant stainless steel cylinder with compact design, featuring enhanced rod guidance system for precise linear motion. The triple sealing structure prevents leakage in high-humidity environments. Includes magnetic piston for position sensing compatibility.
Ideal Applications:
- Food processing machinery (washdown environments)
- Pharmaceutical cleanroom automation
- Semiconductor wafer handling systems
- Marine equipment controls
- Medical sterilization devices
- High-temperature paint spray booths
Maintenance tip:
Relubricate every 3,000 km operation using ISO VG32 hydraulic oil.
Avoid side load exceeding 10N·m. For vertical mounting,
use optional guide bracket (model MFL40-10).
| Property | Property Value |
|---|---|
| sku | MF40X40CAH |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <40mm> |
