Airtac MF32-40 Stainless Steel Mini Cylinder MF40X40SCAH
$55.80
Regular price
$63.30
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MF40X40SCAH
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MF32~40 Stainless Steel Mini Cylinder Series
1. Complies with JIS (Japanese Industrial Standards) specifications;
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. Fixed cushioning pads on both end caps minimize directional reversal impact;
4. Multiple rear cover configurations enhance mounting flexibility;
5. Riveted roller-clamped connection ensures secure and durable body connection between stainless steel barrel and end caps;
6. High-precision stainless steel tubing construction delivers exceptional strength and superior corrosion resistance;
7. Compact profile design: MF series achieves shorter overall length than ISO 6432 standard cylinders with equivalent bore size and stroke;
8. Comprehensive range of cylinder specifications and mounting accessories provides customizable solutions.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MF32~40
Installation note:
For vertical mounting, use anti-drop lock nuts (ADLN-40 accessory).
Lubricate with ISO VG32 hydraulic oil if cycle rate exceeds 500/min.
Maintain 0.3mm minimum clearance from magnetic sensors.
1. Complies with JIS (Japanese Industrial Standards) specifications;
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. Fixed cushioning pads on both end caps minimize directional reversal impact;
4. Multiple rear cover configurations enhance mounting flexibility;
5. Riveted roller-clamped connection ensures secure and durable body connection between stainless steel barrel and end caps;
6. High-precision stainless steel tubing construction delivers exceptional strength and superior corrosion resistance;
7. Compact profile design: MF series achieves shorter overall length than ISO 6432 standard cylinders with equivalent bore size and stroke;
8. Comprehensive range of cylinder specifications and mounting accessories provides customizable solutions.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MF32~40
AirTAC MF40X40SCAH Stainless Steel Mini Cylinder Specifications
- Model: MF40X40SCAH
- Series: MF32~40 stainless steel compact series
- Bore size: 40 mm
- Stroke: 40 mm (customizable: 10-200mm)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 150℃
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Cushioning: Adjustable rubber buffer + shock absorber pad
- Material: SUS304 stainless steel body, NBR seals
- Mounting type: Front flange (MFH series accessories compatible)
- Piston speed: 50-750 mm/s (lubricated)
- Weight: 1.25 kg (bare cylinder), 1.45 kg with accessories
- Dimensions:
- Length: 152 mm (min. retracted length)
- Width: 48 mm (flange mounting base)
- Height: 40 mm (cylinder diameter)
- Rod end: Female thread M10x1.25
- IP rating: IP67 (standard wiper seal)
High-precision corrosion-resistant cylinder with ultra-compact profile, featuring a 0.1mm low-friction piston design for smooth operation. The full stainless steel construction eliminates rust contamination risks, while the dual-cushion system reduces end-impact noise to ≤65dB. Includes built-in magnet for position sensing compatibility.
Ideal Applications:
- Cleanroom automation in semiconductor manufacturing
- Food processing machinery (FDA-compliant lubrication options)
- Chemical dosing systems with acidic environments
- High-cycle packaging lines (rated for 5 million cycles @ 0.5MPa)
- Medical sterilization equipment requiring autoclave compatibility
Installation note:
For vertical mounting, use anti-drop lock nuts (ADLN-40 accessory).
Lubricate with ISO VG32 hydraulic oil if cycle rate exceeds 500/min.
Maintain 0.3mm minimum clearance from magnetic sensors.
| Property | Property Value |
|---|---|
| sku | MF40X40SCAH |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | <40mm> |
