Airtac MF32-40 Stainless Steel Mini Cylinder MF40X450SU
1. Complies with JIS (Japanese Industrial Standards) specifications;
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. Fixed cushioning pads on both end caps minimize directional reversal impact;
4. Multiple rear cover configurations enhance mounting flexibility;
5. Riveted roller-clamped connection ensures secure and durable body connection between stainless steel barrel and end caps;
6. High-precision stainless steel tubing construction delivers exceptional strength and superior corrosion resistance;
7. Compact profile design: MF series achieves shorter overall length than ISO 6432 standard cylinders with equivalent bore size and stroke;
8. Comprehensive range of cylinder specifications and mounting accessories provides customizable solutions.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MF32~40
AirTAC MF40X450SU Stainless Steel Mini Cylinder Specifications
- Series: MF32~40 Compact Cylinder Series
- Model: MF40X450SU
- Bore size: 40mm
- Stroke: 450mm
- Material: Stainless steel (SUS304 barrel/piston rod)
- Operating pressure: 0.05~1.0 MPa
- Temperature range: -20℃ to 150℃
- Cushioning: Adjustable rubber bumper (both ends)
- Port size: M5x0.8 (G1/8 optional)
- Mounting type: Basic (no pre-mount accessories)
- Rod rotation: Non-rotating design
- Weight: 2.45kg ±3%
- Dimensions:
- Extended length: 713mm
- Retracted length: 263mm
- Body diameter: 40mm
- Mounting base: 56mm x 56mm
- ISO standard: 6432 compliant
- Corrosion resistance: Passes 96hr salt spray test
High-precision stainless steel cylinder with extended stroke capability, featuring anti-corrosion construction for harsh environments. The non-rotating piston rod ensures stable linear motion, while the double cushioning system allows smooth deceleration at stroke ends. Requires 5μm filtered air and regular lubrication (ISO VG32 recommended).
- Food processing machinery (washdown environments)
- Pharmaceutical production line actuators
- Semiconductor wafer handling systems
- Marine equipment linear drives
- High-temperature curing oven mechanisms
Installation note:
Ensure proper alignment using guide brackets for strokes over 300mm.
Maximum side load: 15N at full extension. Lubricate through air port
monthly in continuous operation.
| Property | Property Value |
|---|---|
| sku | MF40X450SU |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | 450mm |
