Airtac MF32-40 Stainless Steel Mini Cylinder MF40X50CMTC
1. Complies with JIS (Japanese Industrial Standards) specifications;
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. Fixed cushioning pads on both end caps minimize directional reversal impact;
4. Multiple rear cover configurations enhance mounting flexibility;
5. Riveted roller-clamped connection ensures secure and durable body connection between stainless steel barrel and end caps;
6. High-precision stainless steel tubing construction delivers exceptional strength and superior corrosion resistance;
7. Compact profile design: MF series achieves shorter overall length than ISO 6432 standard cylinders with equivalent bore size and stroke;
8. Comprehensive range of cylinder specifications and mounting accessories provides customizable solutions.
Category: Stainless Steel Mini Cylinders | Brand: AirTAC | Series: MF32~40
AirTAC MF40X50CMTC Stainless Steel Mini Cylinder Specifications
- Model: MF40X50CMTC (MF32~40 series)
- Bore size: 40mm
- Stroke: 50mm
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 150℃
- Port size: M5×0.8 (standard), optional NPT1/8
- Cushioning: Adjustable rubber buffer
- Material: SUS304 stainless steel body, CRCA piston rod
- Seal material: Fluororubber (FKM) for high temp resistance
- Mounting type: Front threaded (M10×1.25), rear foot mounting
- Weight: 0.82kg (with standard accessories)
- Dimensions: 150mm(L) × 54mm(W) × 54mm(H) (fully retracted)
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (relubrication interval: 3,000km)
- Accessories: Optional magnetic switch (D-M9N)
High-precision corrosion-resistant mini cylinder with space-saving design, featuring enhanced side load capacity through integrated guide ribs. The stainless steel construction ensures durability in washdown environments (IP67 equivalent when paired with proper seals). Includes dual anti-rotation pins for stable linear motion.
- Pharmaceutical capsule filling machines
- Semiconductor wafer handling robots
- Food packaging lines with frequent sanitization
- Marine equipment actuators
- High-temperature oven door mechanisms
Installation tip:
Use stainless steel fasteners for corrosion consistency.
Maximum side load: 15N at mid-stroke. For vertical mounting,
add 20% safety factor to thrust calculations.
| Property | Property Value |
|---|---|
| sku | MF40X50CMTC |
| Rear Cover Type | Round Type |
| Mounting Type | Center Pivot Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <50mm> |
