Airtac MG Stainless Steel Mini Air Cylinder MG20X100SLB
The AirTAC Airtac MG Stainless Steel Mini Air Cylinder MG20X100SLB is a genuine double acting JIS-standard round-body mini air cylinder with a Ø20mm bore and 100mm stroke, 1/8" air ports and a SUS304 stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service.
- BoreØ20 mm
- Stroke100 mm
- Port size1/8"
- Acting typeDouble acting
- Rod threadM8×1.25
- CushionFixed anti-impact bumper pads
About the Airtac MG Stainless Steel Mini Air Cylinder MG20X100SLB
Compact and corrosion-ready, the MG20X100SLB is a double acting JIS round-body mini cylinder with a 20 mm bore and 100 mm stroke. Its SUS304 stainless barrel and hard-chrome plated 8 mm rod shrug off damp washdown corners that quickly ruin painted-steel minis, and the riveted covers keep the body short and light. At 0.5 MPa it delivers 157 N push and 131.9 N pull, rising to 219.8 N push at 0.7 MPa, with a theoretical ceiling of 32 kgf at 1.0 MPa.
In practice, plan on roughly 94 N of usable push at 0.5 MPa, which means this cylinder lifts about 8 kg vertically with a sensible margin. The fitted magnet (the S code) lets you mount CMSG, DMSG or EMSG switches for end-of-stroke signalling, and the fixed anti-impact bumper pads soften the direction change at each end. Note that the bumpers only decelerate the piston; if air is lost the rod drifts freely, so use an external rod lock or pilot check valve where a load must stay put.
Airtac MG Stainless Steel Mini Air Cylinder MG20X100SLB Technical Specifications
| Model | Airtac MG Stainless Steel Mini Air Cylinder MG20X100SLB |
|---|---|
| Series | MG JIS mini cylinder |
| Bore size | Ø20 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | 1/8" |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed anti-impact bumper pads |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MG-series (JIS standard) datasheet. Barrel: SUS304 stainless steel (round-body, riveted construction); piston rod: carbon steel with 20µm hard-chrome plating. Thread options: PT (blank) / G / NPT.
Theoretical Output Force (Ø20mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 157 N | 132 N |
| 0.7 MPa | 220 N | 185 N |
| Max (@1.0 MPa) | 32 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MG Stainless Steel Mini Air Cylinder MG20X100SLB
| MG | JIS round-body mini cylinder (double-acting). |
|---|---|
| 20 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
| FA / LB / CB / SDB | Mounting: FA flange, LB foot, CB clevis, SDB pivot bracket (with CB). |
MG-family variants: MG / MGC (double acting ±cushion), MSG / MTG (single acting push / pull), MGD / MGCD (double rod ±cushion). Accessories: LB foot, FA flange, CB clevis, SDB pivot block, plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MG Stainless Steel Mini Air Cylinder MG20X100SLB Is Used
Small-part presence ejection
The built-in magnet and CMSG switch confirm rod position while the 157 N push at 0.5 MPa kicks rejected caps or components off a packaging line conveyor.
Bench-top test fixture clamping
About 94 N of practical clamping force at 0.5 MPa holds small housings or PCB assemblies in a lab jig, and the stainless barrel wipes clean after coolant splashes.
Light lift-and-lower station
Lifts roughly 8 kg vertically with margin, lowering filled vials or small trays between levels on an assembly bench at speeds from 30 to 800 mm/s.
Is the Airtac MG Stainless Steel Mini Air Cylinder MG20X100SLB the Right Cylinder?
At 157 N push (0.5 MPa) this 20 mm bore suits light clamping, ejecting and small-part transfer up to about 8 kg vertical lift. If you need more muscle in the same JIS footprint, step up to the 25 mm bore MG for 245 N push, or drop to a smaller non-MG actuator since 20 mm is the smallest MG bore. The LB foot mount bolts down on a base plate; switch to FA flange, CB clevis or SDB pivot if the kinematics demand it. The 100 mm stroke is well within the 500 mm standard range, and the 8 mm rod tolerates only modest side load, so guide the load externally on long or offset strokes.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting (LB / FA / CB / SDB) & knuckle
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion/impact settings and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MG Stainless Steel Mini Air Cylinder MG20X100SLB FAQ
At 0.5 MPa it pushes with 157 N and pulls with 131.9 N; at 0.7 MPa those figures rise to 219.8 N push and 184.7 N pull. The theoretical maximum is 32 kgf at 1.0 MPa. Operating pressure spans 0.15-1.0 MPa (22-145 psi) with a 1.5 MPa (215 psi) proof pressure, and rod speed runs 30-800 mm/s.
The S in MG20X100SLB means a magnet is built into the piston, so CMSG, DMSG or EMSG reed/solid-state switches can be clipped onto the 1/8"-ported body to signal extend and retract positions. A standard MG without the S code has no magnet and cannot drive these sensors.
