Airtac MG Stainless Steel Mini Air Cylinder MG20X20
The AirTAC Airtac MG Stainless Steel Mini Air Cylinder MG20X20 is a genuine double acting JIS-standard round-body mini air cylinder with a Ø20mm bore and 20mm stroke, 1/8" air ports and a SUS304 stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service.
- BoreØ20 mm
- Stroke20 mm
- Port size1/8"
- Acting typeDouble acting
- Rod threadM8×1.25
- CushionFixed anti-impact bumper pads
About the Airtac MG Stainless Steel Mini Air Cylinder MG20X20
Compact and light, the MG20X20 is a double acting JIS round-body mini cylinder with a 20 mm bore and a short 20 mm stroke. Air drives the rod out and back, and a fixed anti-impact bumper pad at each stroke end softens the direction change - it decelerates only, it is not an adjustable air cushion. At 0.5 MPa the bore delivers about 157 N push and 131.9 N pull, rising to 219.8 N push at 0.7 MPa, with a theoretical maximum of 32 kgf at 1.0 MPa.
The barrel is SUS304 stainless steel riveted onto the covers, paired with a hard-chrome plated 8 mm rod, so the body shrugs off damp, washdown-prone and outdoor spots better than painted-steel minis. Because the footprint follows the JIS mini-cylinder standard, standard brackets and I / Y rod knuckles drop straight on. For sizing, treat roughly 94 N (about 9.6 kg lifted) as the practical vertical load at 0.5 MPa instead of the full rating. Note that this SKU carries no magnet, so CMSG / DMSG / EMSG switches cannot be fitted - order the S code if sensing is needed.
Airtac MG Stainless Steel Mini Air Cylinder MG20X20 Technical Specifications
| Model | Airtac MG Stainless Steel Mini Air Cylinder MG20X20 |
|---|---|
| Series | MG JIS mini cylinder |
| Bore size | Ø20 mm |
| Stroke | 20 mm |
| Acting type | Double acting |
| Port size | 1/8" |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed anti-impact bumper pads |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MG-series (JIS standard) datasheet. Barrel: SUS304 stainless steel (round-body, riveted construction); piston rod: carbon steel with 20µm hard-chrome plating. Thread options: PT (blank) / G / NPT.
Theoretical Output Force (Ø20mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 157 N | 132 N |
| 0.7 MPa | 220 N | 185 N |
| Max (@1.0 MPa) | 32 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MG Stainless Steel Mini Air Cylinder MG20X20
| MG | JIS round-body mini cylinder (double-acting). |
|---|---|
| 20 | Bore size in mm. |
| ×20 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
| FA / LB / CB / SDB | Mounting: FA flange, LB foot, CB clevis, SDB pivot bracket (with CB). |
MG-family variants: MG / MGC (double acting ±cushion), MSG / MTG (single acting push / pull), MGD / MGCD (double rod ±cushion). Accessories: LB foot, FA flange, CB clevis, SDB pivot block, plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MG Stainless Steel Mini Air Cylinder MG20X20 Is Used
Small-part clamping on assembly fixtures
The 157 N push at 0.5 MPa is enough to hold small brackets or PCB housings in drill and press fixtures, and the 20 mm stroke fits tight fixture plates.
Ejecting parts from packaging chutes
A short push of about 9.6 kg equivalent vertical load nudges cartons or blisters off a chute stop, with the bumper pad quieting each stroke end.
Sample positioning in lab automation
The SUS304 stainless barrel tolerates frequent wipe-downs in analytical and sample-handling equipment, and the JIS footprint suits compact custom gantries.
Is the Airtac MG Stainless Steel Mini Air Cylinder MG20X20 the Right Cylinder?
At 20 mm bore this is the smallest MG, so there is no step down within the series; if 157 N push at 0.5 MPa is marginal, step up to the 25 mm bore (about 245 N) or the 32 mm bore (about 402 N). The 20 mm stroke suits short clamp or eject moves. Keep in mind that when air is lost the piston drifts freely - the bumpers do not lock anything - so add an external rod lock or a pilot check valve if the position must be held. Mount with LB foot, FA flange, CB clevis or SDB pivot, and add the S magnet code if you plan to fit CMSG / DMSG / EMSG switches.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting (LB / FA / CB / SDB) & knuckle
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion/impact settings and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MG Stainless Steel Mini Air Cylinder MG20X20 FAQ
Push is 157 N and pull is 131.9 N at 0.5 MPa; at 0.7 MPa push is 219.8 N and pull 184.7 N; theoretical maximum is 32 kgf at 1.0 MPa. It is a double acting JIS mini cylinder, 20 mm bore, 20 mm stroke, 8 mm rod with M8x1.25 male thread, 1/8" ports, operating pressure 0.15-1.0 MPa (22-145 psi), proof 1.5 MPa (215 psi), speed 30-800 mm/s, temperature -20 to +70 C.
Not on this SKU. It has no built-in magnet, and the CMSG / DMSG / EMSG switches only work on cylinders ordered with the S magnet code. Also remember the fixed bumper pads only soften the stroke end - they are not an adjustable cushion and do not hold a load if air is lost.
