Airtac MG Stainless Steel Mini Air Cylinder MG20X200
The AirTAC Airtac MG Stainless Steel Mini Air Cylinder MG20X200 is a genuine double acting JIS-standard round-body mini air cylinder with a Ø20mm bore and 200mm stroke, 1/8" air ports and a SUS304 stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service.
- BoreØ20 mm
- Stroke200 mm
- Port size1/8"
- Acting typeDouble acting
- Rod threadM8×1.25
- CushionFixed anti-impact bumper pads
About the Airtac MG Stainless Steel Mini Air Cylinder MG20X200
A compact round-body actuator built to the JIS mini-cylinder standard, the MG20X200 works double acting: air drives the 20 mm piston out and pulls it back, with no spring involved. At the standard 0.5 MPa shop supply it pushes with 157 N and pulls with 131.9 N, rising to 219.8 N and 184.7 N at 0.7 MPa. Its 200 mm stroke suits slim spaces where a longer body would not fit, and the fixed anti-impact bumper pads at each end soften the direction change without acting as a cushion or a brake.
The barrel is SUS304 stainless steel riveted onto the covers, paired with a hard-chrome plated 8 mm rod, so the body shrugs off damp air, light washdown and outdoor duty far better than painted minis. Because the footprint follows the JIS mini standard, standard brackets and I or Y rod knuckles bolt straight on. As a working rule, budget roughly 94 N of that 157 N push for real work at 0.5 MPa, which is about 9 kg of vertical lift with a sensible margin. Note that the rod drifts if air is lost, so add an external check valve or rod lock where a load must stay put.
Airtac MG Stainless Steel Mini Air Cylinder MG20X200 Technical Specifications
| Model | Airtac MG Stainless Steel Mini Air Cylinder MG20X200 |
|---|---|
| Series | MG JIS mini cylinder |
| Bore size | Ø20 mm |
| Stroke | 200 mm |
| Acting type | Double acting |
| Port size | 1/8" |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed anti-impact bumper pads |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MG-series (JIS standard) datasheet. Barrel: SUS304 stainless steel (round-body, riveted construction); piston rod: carbon steel with 20µm hard-chrome plating. Thread options: PT (blank) / G / NPT.
Theoretical Output Force (Ø20mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 157 N | 132 N |
| 0.7 MPa | 220 N | 185 N |
| Max (@1.0 MPa) | 32 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MG Stainless Steel Mini Air Cylinder MG20X200
| MG | JIS round-body mini cylinder (double-acting). |
|---|---|
| 20 | Bore size in mm. |
| ×200 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
| FA / LB / CB / SDB | Mounting: FA flange, LB foot, CB clevis, SDB pivot bracket (with CB). |
MG-family variants: MG / MGC (double acting ±cushion), MSG / MTG (single acting push / pull), MGD / MGCD (double rod ±cushion). Accessories: LB foot, FA flange, CB clevis, SDB pivot block, plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MG Stainless Steel Mini Air Cylinder MG20X200 Is Used
Lab sample pusher
The 157 N push at 0.5 MPa gently advances sample trays into an analyzer, while the stainless barrel tolerates frequent wipe-downs.
Small-part diverting on conveyors
With a 200 mm reach, the rod kicks light cartons or blisters off a narrow conveyor lane; the bumper pad softens each reversal.
Lid lifting on packaging jigs
Lifts roughly 9 kg of jig lid vertically with margin at 0.5 MPa, and the compact round body fits tight machine frames.
Is the Airtac MG Stainless Steel Mini Air Cylinder MG20X200 the Right Cylinder?
At 157 N push (0.5 MPa) this 20 mm bore is the smallest MG size, so if your load needs more, step up to the 25 mm bore at 245.3 N or the 32 mm bore at 402.2 N; there is no smaller MG below it. The 200 mm stroke is within the 500 mm standard range, but at this length keep side loads off the 8 mm rod and guide the load externally. Mounting choices are LB foot, FA flange, CB clevis or SDB pivot; this SKU has no S magnet, so CMSG, DMSG or EMSG switches cannot be fitted unless you order the S version. If higher speeds or heavier loads hammer the stroke ends, the cushioned MGC in the same bore family is the alternative.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting (LB / FA / CB / SDB) & knuckle
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion/impact settings and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MG Stainless Steel Mini Air Cylinder MG20X200 FAQ
At 0.5 MPa it pushes 157 N and pulls 131.9 N; at 0.7 MPa, 219.8 N push and 184.7 N pull. The theoretical maximum is 32 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi) with 1.5 MPa (215 psi) proof pressure, speed 30-800 mm/s, and a 1/8" port on every bore of this series.
Not as supplied. This SKU has no S magnet, and the CMSG, DMSG or EMSG switches only trigger on the magnetized piston, so order the MG20X200S version for sensing. The bumper pads only decelerate the stroke end; they do not hold the rod, and the cylinder drifts when air is removed.
