Airtac MG Stainless Steel Mini Air Cylinder MG20X250
The AirTAC Airtac MG Stainless Steel Mini Air Cylinder MG20X250 is a genuine double acting JIS-standard round-body mini air cylinder with a Ø20mm bore and 250mm stroke, 1/8" air ports and a SUS304 stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service.
- BoreØ20 mm
- Stroke250 mm
- Port size1/8"
- Acting typeDouble acting
- Rod threadM8×1.25
- CushionFixed anti-impact bumper pads
About the Airtac MG Stainless Steel Mini Air Cylinder MG20X250
With a 20 mm bore and a 250 mm stroke, this MG cylinder is a double acting JIS round-body mini cylinder built around a SUS304 stainless barrel riveted to its covers, with a hard-chrome plated 8 mm rod. The fixed anti-impact pad at each stroke end softens the direction change; it decelerates only and is not an adjustable air cushion. Because the MG follows the JIS mini-cylinder standard, its footprint drops onto standard JIS brackets and rod knuckles, which makes spares and redesigns straightforward.
At 0.5 MPa the bore pushes about 157 N and pulls about 131.9 N; at 0.7 MPa those rise to 219.8 N and 184.7 N, with a theoretical maximum of 32 kgf at 1.0 MPa. In practice, plan on roughly 94 N of usable work at 0.5 MPa, which is about 8 kg of vertical lifting with a 2:1 margin. The stainless barrel also shrugs off damp, washdown-prone spots where painted minis corrode. Note that this SKU has no magnet, so no CMSG / DMSG / EMSG sensor can be fitted; order the S code if position detection is needed.
Airtac MG Stainless Steel Mini Air Cylinder MG20X250 Technical Specifications
| Model | Airtac MG Stainless Steel Mini Air Cylinder MG20X250 |
|---|---|
| Series | MG JIS mini cylinder |
| Bore size | Ø20 mm |
| Stroke | 250 mm |
| Acting type | Double acting |
| Port size | 1/8" |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed anti-impact bumper pads |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MG-series (JIS standard) datasheet. Barrel: SUS304 stainless steel (round-body, riveted construction); piston rod: carbon steel with 20µm hard-chrome plating. Thread options: PT (blank) / G / NPT.
Theoretical Output Force (Ø20mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 157 N | 132 N |
| 0.7 MPa | 220 N | 185 N |
| Max (@1.0 MPa) | 32 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MG Stainless Steel Mini Air Cylinder MG20X250
| MG | JIS round-body mini cylinder (double-acting). |
|---|---|
| 20 | Bore size in mm. |
| ×250 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
| FA / LB / CB / SDB | Mounting: FA flange, LB foot, CB clevis, SDB pivot bracket (with CB). |
MG-family variants: MG / MGC (double acting ±cushion), MSG / MTG (single acting push / pull), MGD / MGCD (double rod ±cushion). Accessories: LB foot, FA flange, CB clevis, SDB pivot block, plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MG Stainless Steel Mini Air Cylinder MG20X250 Is Used
Carton flap tuck-down
A 250 mm reach lets the 157 N push at 0.5 MPa fold tall carton flaps on a packaging line without the cylinder crowding the machine frame.
Bottle pusher on a conveyor
The long stroke sweeps small bottles or cartons sideways off a belt; the fixed bumper pads quiet the stroke ends at each push.
Lab sample elevator
Lifting sample trays of about 8 kg vertically within the 2:1 margin, with the stainless barrel tolerating frequent wipe-downs in a clean bench area.
Is the Airtac MG Stainless Steel Mini Air Cylinder MG20X250 the Right Cylinder?
At 157 N push at 0.5 MPa, the 20 mm bore suits light clamping, ejecting and sorting tasks. If your load needs more, step up to the 25 mm bore at about 245 N push at 0.5 MPa; if 157 N is generous for the job, there is no smaller MG bore, so consider the single-acting MSG/MTG family instead. The 250 mm stroke is well inside the 500 mm standard range for this bore, but a long thin 8 mm rod invites side load: guide the workpiece or use external guidance to protect the rod and seals. Mount with LB foot, FA flange, CB clevis or SDB pivot, and remember that a plain MG drifts when air is lost - it holds nothing on its own, so add a pilot check valve or external rod lock where a load must stay put.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting (LB / FA / CB / SDB) & knuckle
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion/impact settings and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MG Stainless Steel Mini Air Cylinder MG20X250 FAQ
At 0.5 MPa it pushes 157 N and pulls 131.9 N; at 0.7 MPa it pushes 219.8 N and pulls 184.7 N. The theoretical maximum is 32 kgf at 1.0 MPa. It runs on 0.15-1.0 MPa (22-145 psi) air filtered to 40 um, at 30-800 mm/s and -20 to +70 C, with a 1/8" port and an M8x1.25 male rod thread.
Not as ordered - this SKU has no magnet, so no switch can be mounted. Specify the S code (for example MG20X250S) to enable CMSG, DMSG or EMSG reed or solid-state switches. The fixed bumper pads soften the stroke ends but do not brake or hold the load; when air is lost the rod drifts freely.
