Airtac MG Stainless Steel Mini Air Cylinder MG20X300
The AirTAC Airtac MG Stainless Steel Mini Air Cylinder MG20X300 is a genuine double acting JIS-standard round-body mini air cylinder with a Ø20mm bore and 300mm stroke, 1/8" air ports and a SUS304 stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service.
- BoreØ20 mm
- Stroke300 mm
- Port size1/8"
- Acting typeDouble acting
- Rod threadM8×1.25
- CushionFixed anti-impact bumper pads
About the Airtac MG Stainless Steel Mini Air Cylinder MG20X300
With a 300 mm stroke on a 20 mm bore, this MG cylinder reaches deep into guarding and fixtures while staying double acting: air drives the rod out and pulls it back, so there is no spring to rob force. At 0.5 MPa it pushes 157 N and pulls 131.9 N; at 0.7 MPa those figures rise to 219.8 N and 184.7 N, with a theoretical ceiling of 32 kgf at 1.0 MPa. The round SUS304 stainless barrel and hard-chrome plated 8 mm rod shrug off washdown and damp shop air far better than painted aluminium minis, and the riveted body keeps the whole unit slim and light.
For sizing the work, plan on roughly 94 N of usable push at 0.5 MPa (about 60% of the rating), which translates to lifting around 9 kg vertically with a 2:1 margin. Because the bore follows the JIS mini-cylinder standard, standard JIS brackets and I/Y rod knuckles bolt straight on. Note that the fixed anti-impact bumper pads only soften the stroke ends - they are not an adjustable cushion and they will not hold a load if air pressure drops. The 1/8" ports take PT threading, and speed runs 30-800 mm/s across a 0.15-1.0 MPa (22-145 psi) supply.
Airtac MG Stainless Steel Mini Air Cylinder MG20X300 Technical Specifications
| Model | Airtac MG Stainless Steel Mini Air Cylinder MG20X300 |
|---|---|
| Series | MG JIS mini cylinder |
| Bore size | Ø20 mm |
| Stroke | 300 mm |
| Acting type | Double acting |
| Port size | 1/8" |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed anti-impact bumper pads |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MG-series (JIS standard) datasheet. Barrel: SUS304 stainless steel (round-body, riveted construction); piston rod: carbon steel with 20µm hard-chrome plating. Thread options: PT (blank) / G / NPT.
Theoretical Output Force (Ø20mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 157 N | 132 N |
| 0.7 MPa | 220 N | 185 N |
| Max (@1.0 MPa) | 32 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MG Stainless Steel Mini Air Cylinder MG20X300
| MG | JIS round-body mini cylinder (double-acting). |
|---|---|
| 20 | Bore size in mm. |
| ×300 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
| FA / LB / CB / SDB | Mounting: FA flange, LB foot, CB clevis, SDB pivot bracket (with CB). |
MG-family variants: MG / MGC (double acting ±cushion), MSG / MTG (single acting push / pull), MGD / MGCD (double rod ±cushion). Accessories: LB foot, FA flange, CB clevis, SDB pivot block, plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MG Stainless Steel Mini Air Cylinder MG20X300 Is Used
Carton flap tuck-in
The 300 mm reach lets the 157 N push swing tall carton flaps down on a packaging line without the cylinder body intruding into the box path.
Sample tray ejector
Lab and diagnostic analysers use the long stroke to push sample trays from a magazine; the stainless barrel tolerates frequent wipe-downs.
Light conveyor stopper
Rising against moving totes, the rod stops parts weighing up to about 9 kg with margin, the bumper pad absorbing the arrival shock at each end of travel.
Is the Airtac MG Stainless Steel Mini Air Cylinder MG20X300 the Right Cylinder?
At 157 N push (0.5 MPa) this 20 mm bore suits light clamping, ejecting small parts and sensing-type positioning; step down is not possible within MG (20 mm is the smallest), while the 25 mm bore gives 245.3 N and the 32 mm bore 402.2 N if your load grows. The 300 mm stroke is well inside the 500 mm standard range, but a long slender 8 mm rod dislikes side loads - guide the part or add external linear guides if the stroke is not purely axial. This SKU carries no magnet, so CMSG/DMSG/EMSG switches cannot be fitted; order the -S version if you need position sensing. If the load must stay put when air is lost, add a pilot check valve or external rod lock - the bumpers only decelerate.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting (LB / FA / CB / SDB) & knuckle
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion/impact settings and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MG Stainless Steel Mini Air Cylinder MG20X300 FAQ
At 0.5 MPa it pushes 157 N and pulls 131.9 N; at 0.7 MPa, 219.8 N push and 184.7 N pull. The theoretical maximum is 32 kgf at 1.0 MPa. Operating pressure is 0.15-1.0 MPa (22-145 psi), proof pressure 1.5 MPa (215 psi), speed 30-800 mm/s, temperature -20 to +70 C, with air filtered to 40 um through 1/8" PT ports.
Not as supplied - this SKU has no built-in magnet, so CMSG, DMSG or EMSG switches cannot detect the piston. Order the MG20X300S variant, whose -S magnet enables those switches. Also remember the fixed bumper pads only soften stroke-end impact; they are not an adjustable cushion and provide no load holding.
