Airtac MG Stainless Steel Mini Air Cylinder MG25X125
The AirTAC Airtac MG Stainless Steel Mini Air Cylinder MG25X125 is a genuine double acting JIS-standard round-body mini air cylinder with a Ø25mm bore and 125mm stroke, 1/8" air ports and a SUS304 stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service.
- BoreØ25 mm
- Stroke125 mm
- Port size1/8"
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionFixed anti-impact bumper pads
About the Airtac MG Stainless Steel Mini Air Cylinder MG25X125
With a 25 mm bore and 125 mm stroke, this AirTAC MG25X125 is a double acting JIS round-body mini cylinder that pushes with 245.3 N and pulls with 206.1 N at 0.5 MPa, rising to 343.4 N on the extend stroke at 0.7 MPa. The barrel is SUS304 stainless steel riveted to the covers, so the body shrugs off damp air, light washdown and outdoor duty far better than painted-steel minis, while the hard-chrome plated 10 mm rod keeps wear low.
In practice the 245.3 N push converts to roughly 25 kgf, so planning for about 12 kg of vertical lifting keeps a comfortable margin on a real part. The fixed anti-impact bumper pad at each stroke end softens direction changes but does not cushion adjustably, and the piston will drift if air is lost, so add an external check or rod lock where a load must stay put. Note that this SKU carries no magnet, so CMSG, DMSG or EMSG switches cannot be fitted unless you order the S code.
Airtac MG Stainless Steel Mini Air Cylinder MG25X125 Technical Specifications
| Model | Airtac MG Stainless Steel Mini Air Cylinder MG25X125 |
|---|---|
| Series | MG JIS mini cylinder |
| Bore size | Ø25 mm |
| Stroke | 125 mm |
| Acting type | Double acting |
| Port size | 1/8" |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed anti-impact bumper pads |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MG-series (JIS standard) datasheet. Barrel: SUS304 stainless steel (round-body, riveted construction); piston rod: carbon steel with 20µm hard-chrome plating. Thread options: PT (blank) / G / NPT.
Theoretical Output Force (Ø25mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 245 N | 206 N |
| 0.7 MPa | 344 N | 289 N |
| Max (@1.0 MPa) | 50 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MG Stainless Steel Mini Air Cylinder MG25X125
| MG | JIS round-body mini cylinder (double-acting). |
|---|---|
| 25 | Bore size in mm. |
| ×125 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
| FA / LB / CB / SDB | Mounting: FA flange, LB foot, CB clevis, SDB pivot bracket (with CB). |
MG-family variants: MG / MGC (double acting ±cushion), MSG / MTG (single acting push / pull), MGD / MGCD (double rod ±cushion). Accessories: LB foot, FA flange, CB clevis, SDB pivot block, plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MG Stainless Steel Mini Air Cylinder MG25X125 Is Used
Bottle reject pusher on a filling line
A 245.3 N push at 0.5 MPa is ample to kick off-spec bottles or cartons sideways off a conveyor, and the stainless barrel tolerates frequent wipe-downs.
Small part press-fit in electronics assembly
Around 25 kgf of theoretical force suits pressing bushings or terminals into plastic housings, with the bumper pad damping the end of each 125 mm stroke.
Gate latch on a pick-module slide
The compact riveted round body fits tight warehouse slide frames, and the 125 mm throw locks and releases light gates without needing a cushion.
Is the Airtac MG Stainless Steel Mini Air Cylinder MG25X125 the Right Cylinder?
Size against neighbours: the MG20X125 delivers 157.0 N push at 0.5 MPa, while stepping up to MG32X125 gives 402.2 N, so the 25 mm bore sits comfortably between them for medium mini-cylinder tasks. Mount it LB foot, FA flange, CB clevis or SDB pivot, and pair with I or Y rod knuckles on the M10x1.25 male thread. At 125 mm stroke the standard range (up to 500 mm) still applies, so no made-to-order surcharge is expected. If your cycle runs fast with heavy tooling, the cushioned MGC bore 25 is the better match; if you need position sensing, order the magnet version MG25X125S.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting (LB / FA / CB / SDB) & knuckle
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion/impact settings and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MG Stainless Steel Mini Air Cylinder MG25X125 FAQ
At 0.5 MPa it pushes 245.3 N and pulls 206.1 N; at 0.7 MPa those rise to 343.4 N and 288.5 N; theoretical maximum is 50 kgf at 1.0 MPa. Operating pressure is 0.15-1.0 MPa (22-145 psi) with a 1.5 MPa (215 psi) proof pressure, air filtered to 40 um, speed 30-800 mm/s and temperature -20 to +70 C. The port is 1/8" and the rod thread is M10x1.25.
Not on this SKU: it has no built-in magnet, and the CMSG, DMSG and EMSG switches only work on cylinders ordered with the S magnet code. Choose MG25X125S if you need switching. Also remember the bumper pads only soften stroke-end impact; they do not hold the rod against air loss.
