Airtac MG Stainless Steel Mini Air Cylinder MG40X300
The AirTAC Airtac MG Stainless Steel Mini Air Cylinder MG40X300 is a genuine double acting JIS-standard round-body mini air cylinder with a Ø40mm bore and 300mm stroke, 1/8" air ports and a SUS304 stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service.
- BoreØ40 mm
- Stroke300 mm
- Port size1/8"
- Acting typeDouble acting
- Rod threadM14×1.5
- CushionFixed anti-impact bumper pads
About the Airtac MG Stainless Steel Mini Air Cylinder MG40X300
With a 40 mm bore pushing 628.3 N at 0.5 MPa (879.6 N at 0.7 MPa), the MG40X300 is the strongest standard bore in AirTAC's MG family: a double acting, JIS round-body mini cylinder with a 300 mm stroke and a 16 mm hard-chrome-plated rod. The SUS304 stainless barrel is riveted to the covers rather than tied together with rods, so the body stays compact and shrugs off washdown and damp shop air that swells painted-steel minis.
At the stroke ends a fixed anti-impact bumper pad decelerates the piston, softening direction changes at the 300 mm travel - it is not an adjustable air cushion, which is the MGC variant. The bore 40 port is 1/8" and the male rod thread is M14x1.5. As a rule of thumb, plan on roughly 377 N of usable work at 0.5 MPa, which lifts about 32 kg vertically with a 2:1 margin.
Airtac MG Stainless Steel Mini Air Cylinder MG40X300 Technical Specifications
| Model | Airtac MG Stainless Steel Mini Air Cylinder MG40X300 |
|---|---|
| Series | MG JIS mini cylinder |
| Bore size | Ø40 mm |
| Stroke | 300 mm |
| Acting type | Double acting |
| Port size | 1/8" |
| Rod thread | M14×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed anti-impact bumper pads |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MG-series (JIS standard) datasheet. Barrel: SUS304 stainless steel (round-body, riveted construction); piston rod: carbon steel with 20µm hard-chrome plating. Thread options: PT (blank) / G / NPT.
Theoretical Output Force (Ø40mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 628 N | 528 N |
| 0.7 MPa | 880 N | 739 N |
| Max (@1.0 MPa) | 128 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MG Stainless Steel Mini Air Cylinder MG40X300
| MG | JIS round-body mini cylinder (double-acting). |
|---|---|
| 40 | Bore size in mm. |
| ×300 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
| FA / LB / CB / SDB | Mounting: FA flange, LB foot, CB clevis, SDB pivot bracket (with CB). |
MG-family variants: MG / MGC (double acting ±cushion), MSG / MTG (single acting push / pull), MGD / MGCD (double rod ±cushion). Accessories: LB foot, FA flange, CB clevis, SDB pivot block, plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MG Stainless Steel Mini Air Cylinder MG40X300 Is Used
Pallet-stacker gate actuator
The 628.3 N push at 0.5 MPa swings heavy pallet-gate arms on warehouse trucks, and the stainless barrel survives outdoor yards and rain.
Bottling-line pusher bar
A 300 mm stroke sweeps full crates across a conveyor lane; the fixed bumper pad softens each reversal at up to 800 mm/s cycle speed.
Fish-processing tray ejector
Washdown-grade SUS304 construction and a hard-chrome rod keep the 40 mm bore moving brine-splashed trays where painted minis corrode.
Is the Airtac MG Stainless Steel Mini Air Cylinder MG40X300 the Right Cylinder?
Compare by 0.5 MPa push force: the bore 32 MG delivers 402.2 N, so step up to this 40 mm bore when your clamp or lift needs 628.3 N; there is no larger standard MG bore - for more force move to the cushioned MGC, which extends the range to 50 and 63 mm. Remember a plain MG does not hold position when air is lost: the piston drifts, so add an external rod lock or a pilot check valve if the load must stay put.
This SKU has no magnet, so CMSG / DMSG / EMSG switches cannot be fitted - order the S code if you need position sensing. Mount it with LB foot, FA flange or CB clevis brackets (SDB pivot with CB), and use I or Y rod knuckles on the M14x1.5 thread. At 300 mm of travel, keep side loads off the 16 mm rod or guide the load externally to avoid rod bending.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting (LB / FA / CB / SDB) & knuckle
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion/impact settings and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MG Stainless Steel Mini Air Cylinder MG40X300 FAQ
At 0.5 MPa it pushes 628.3 N and pulls 527.8 N; at 0.7 MPa it pushes 879.6 N and pulls 738.9 N. The theoretical maximum is 128.1 kgf at 1.0 MPa. Operating pressure is 0.15-1.0 MPa (22-145 psi), proof pressure 1.5 MPa (215 psi), speed 30-800 mm/s, and the port on every bore 40 MG is 1/8".
Not as supplied - this SKU has no magnet, so CMSG / DMSG / EMSG switches cannot detect it; order the S code version for sensing. Mechanically it is a JIS-standard round-body cylinder with a riveted SUS304 stainless barrel, hard-chrome-plated 16 mm rod, and fixed anti-impact bumper pads that only soften the stroke ends.
