Airtac MGCD Stainless Steel Mini Air Cylinder MGCD20X150S
The AirTAC Airtac MGCD Stainless Steel Mini Air Cylinder MGCD20X150S is a genuine double acting, double rod + cushion JIS-standard round-body mini air cylinder with a Ø20mm bore and 150mm stroke, M5×0.8 air ports and a SUS304 stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service.
- BoreØ20 mm
- Stroke150 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod + cushion
- Rod threadM8×1.25
- CushionVariable air cushion, both ends
About the Airtac MGCD Stainless Steel Mini Air Cylinder MGCD20X150S
The AirTAC MGCD20X150S is a double acting, double-rod JIS round-body mini cylinder with a 20 mm bore and 150 mm stroke, fitted with a variable air cushion at both ends. Because a rod exits both covers and both sides of the piston see the rod-side area, the output force is equal in both directions: about 131.9 N at 0.5 MPa and 184.7 N at 0.7 MPa, with a theoretical maximum of 26.9 kgf at 1.0 MPa. The adjustable cushion decelerates the piston smoothly at each end of the stroke, so this small cylinder can handle higher speeds and heavier loads than an un-cushioned equivalent. The magnet fitted as standard (the S code) allows CMSG, DMSG or EMSG switches to be mounted for end-of-stroke sensing.
Construction follows the JIS mini-cylinder footprint: a SUS304 stainless barrel with hard-chrome plated rods, riveted covers and a two-way lubricant-storing piston seal. Ports are M5x0.8 and the male rod thread is M8x1.25 on both ends, so the rear rod end can carry a stop flag, a second load or a position indicator. For a realistic working load, apply about 0.6 of the push force: roughly 8 kgf horizontally, or about 4 kgf as a safe vertical figure at 0.5 MPa. Operating range is 0.15-1.0 MPa (22-145 psi), proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, and speed 30-800 mm/s, with air filtered to 40 um.
Airtac MGCD Stainless Steel Mini Air Cylinder MGCD20X150S Technical Specifications
| Model | Airtac MGCD Stainless Steel Mini Air Cylinder MGCD20X150S |
|---|---|
| Series | MGCD JIS mini cylinder |
| Bore size | Ø20 mm |
| Stroke | 150 mm |
| Acting type | Double acting, double rod + cushion |
| Port size | M5×0.8 |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC MG-series (JIS standard) datasheet. Barrel: SUS304 stainless steel (round-body, riveted construction); piston rod: carbon steel with 20µm hard-chrome plating. Thread options: PT (blank) / G / NPT.
Theoretical Output Force (Ø20mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 132 N |
| 0.7 MPa | 185 N |
| Max (@1.0 MPa) | 27 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac MGCD Stainless Steel Mini Air Cylinder MGCD20X150S
| MGCD | JIS round-body mini cylinder (double-rod, variable cushion). |
|---|---|
| 20 | Bore size in mm. |
| ×150 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
| FA / LB | Mounting: FA flange, LB foot. |
MG-family variants: MG / MGC (double acting ±cushion), MSG / MTG (single acting push / pull), MGD / MGCD (double rod ±cushion). Accessories: LB foot, FA flange, plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MGCD Stainless Steel Mini Air Cylinder MGCD20X150S Is Used
High-speed anti-rotation transfer
The through rod guides a small carrier without extra rails while the variable air cushion absorbs the stop at 150 mm travel, letting the 131.9 N push run at the top of the 30-800 mm/s speed range without hard impact.
Twin-load light press with soft stop
Rod ends on both covers let this 20 mm bore cylinder press two light parts at once, each seeing about 13 kgf at 0.5 MPa, while the adjustable cushion gives a smooth, non-jarring end of stroke.
Rear-switch slide with position flag
The rear rod end carries a stop or position flag while the magnet and a CMSG or DMSG switch signal stroke ends, making the MGCD20X150S a compact sensing slide for small assembly or inspection stations.
Is the Airtac MGCD Stainless Steel Mini Air Cylinder MGCD20X150S the Right Cylinder?
Size the MGCD20X150S when your load needs roughly 130 N or less in both directions at 0.5 MPa; step up to MGCD25 or MGCD32 if you need more force, or down is not possible since bore 20 is the smallest in the range. Choose the MGCD double-rod cushioned type over the MGD (double rod with fixed bumper, bores 20-40) when you need adjustable deceleration for high-speed or heavier-load stops, and over the MGC (single rod plus cushion) when you specifically need a through rod for anti-rotation guidance, a rear stop flag or a second load. Mounting is LB foot or FA flange, with I and Y rod knuckles available; note there is no CB or SDB option on this family. The fitted magnet works with CMSG, DMSG and EMSG switches. The maximum standard stroke for bore 20 is 300 mm, so 150 mm is comfortably within range; for strokes beyond 300 mm on this bore, request a nonstandard build and support the rod against side load.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting (LB / FA) & knuckle
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MGCD Stainless Steel Mini Air Cylinder MGCD20X150S FAQ
Because it is a double-rod cylinder, the force is equal in both directions: 131.9 N at 0.5 MPa and 184.7 N at 0.7 MPa, with a theoretical maximum of 26.9 kgf at 1.0 MPa. It is double acting, runs on air filtered to 40 um at 0.15-1.0 MPa (22-145 psi), withstands a proof pressure of 1.5 MPa (215 psi), operates from -20 to +70 C at 30-800 mm/s, and its maximum standard stroke at bore 20 is 300 mm.
The cushion is an adjustable air cushion at both ends that decelerates the piston near each stroke end, so you can tune the stop for higher speeds or heavier loads; it is not a lock, so use an external rod lock or pilot check valve if the load must be held on air loss. Unlike the MGD, which uses fixed bumper pads, the MGCD cushion is adjustable, and unlike the single-rod MGC, the MGCD has a rod at both covers, giving equal force both ways and a rear rod end for a flag or second load. The fitted magnet also accepts CMSG, DMSG or EMSG switches.
