Airtac MI25~40 Stainless Steel Mini Cylinder MI25X100SCM
2. Integrated shock-absorbing pads on front/rear covers mitigate impact during direction changes;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped and rolled structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Stainless steel piston rods and cylinders provide corrosion resistance for harsh operating environments;
6. Comprehensive range of specifications and mounting accessories available for customized solutions.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MI25~40
AirTAC MI25X100SCM Stainless Steel Miniature Cylinder Specifications
- Series: MI25~40 Stainless Steel Series
- Bore size: 25mm
- Stroke: 100mm
- Material: SUS304 stainless steel (body & rod)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Piston speed: 50–800 mm/s
- Seal material: Fluororubber (FKM) for high chemical resistance
- Mounting type: Basic type (no built-in mounts)
- Weight: 0.68 kg (1.5 lbs)
- Dimensions:
- Length: 136mm (fully retracted)
- Width: 32mm (max body diameter)
- Height: 32mm (same as width, cylindrical body)
Corrosion-resistant miniature cylinder with full stainless steel construction, designed for harsh environments requiring frequent washdowns or chemical exposure. Features precision-ground rod and double lip seals for minimal leakage. Requires air lubrication (ISO VG32 or equivalent recommended).
- Pharmaceutical manufacturing cleanrooms
- Food processing machinery actuators
- Marine equipment controls
- Semiconductor wafer handling systems
- Laboratory automation with corrosive vapors
Installation note:
Use stainless steel compatible lubricants only. For vertical mounting,
add drip pan to prevent fluid ingress. Max side load: 15N at full extension.
| Property | Property Value |
|---|---|
| sku | MI25X100SCM |
| Rear Cover Type | Round Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | 100mm |
