Airtac MIC Cushioned Mini Cylinder MIC16X10SCM
AirTAC MIC16X10SCM Cushioned Miniature Cylinder Specifications
- Model: MIC16X10SCM
- Type: Double-acting with adjustable cushioning
- Bore size: 16mm
- Stroke: 10mm (±0.5mm)
- Cushion type: SCM (Soft Cushion Mechanism)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5×0.8 (Standard) / NPT1/8 (Optional)
- Mounting style: Basic foot mount (MF1) with through-hole
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Weight: 0.12kg (excluding accessories)
- Dimensions: 50mm(L) × 16mm(W) × 16mm(H) (Minimum retracted length)
- Max piston speed: 500mm/s
- Lubrication: Pre-lubricated (Grease-free operation)
- Repeat accuracy: ±0.1mm
Ultra-compact pneumatic cylinder featuring patented SCM technology that reduces end-impact noise by 30% compared to standard models. The precision-ground stainless steel rod and dual lip seals ensure leak-proof operation even in high-cycle applications (up to 1.5 million cycles). Integrated mounting slots enable tool-free installation adjustments.
- PCB handling robots in electronics manufacturing
- Micro-dosing valves in medical analyzers
- Precision clamping in watchmaking CNC fixtures
- Sorting gates for small parcel logistics systems
- Lens positioning in optical equipment assembly
Installation tip:
For optimal performance, maintain 0.5-1mm clearance between cushion screws and end caps during alignment.
Use Cushion Lock adhesive (AIRTAC CL-242) after adjustment.
| Property | Property Value |
|---|---|
| sku | MIC16X10SCM |
| Rear Cover Type | Round Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
