Airtac MIC Cushioned Mini Cylinder MIC16X10SU
AirTAC MIC16X10SU Cushioned Miniature Cylinder Specifications
- Model: MIC16X10SU
- Bore Size: 16mm
- Stroke: 10mm
- Operation Type: Double-acting
- Cushioning Type: Adjustable buffer (both ends)
- Operating Pressure: 0.15–0.8 MPa
- Temperature Range: -20℃ to 80℃
- Piston Speed: 50–800 mm/s
- Mounting Style: U-shaped base with 2x M5 threaded holes
- Rod Thread: M5×0.8 (external)
- Seal Material: NBR (Nitrile Rubber)
- Weight: 0.12 kg
- Dimensions: 58mm(L) × 34mm(W) × 34mm(H) (excluding rod extension)
- Port Size: M5×0.8 (air inlet/outlet)
- Protection Rating: IP40
- Lubrication: Pre-lubricated (maintenance-free for 2000km travel)
A precision-engineered mini cylinder featuring dual adjustable air cushions for smooth end-of-stroke deceleration. The hardened stainless steel piston rod and anodized aluminum body ensure durability in high-cycle applications. Designed for ISO 6432 compliance with 0.5mm maximum allowable parallel rod misalignment.
- PCB handling robots in electronics assembly
- Lab automation sample positioning stages
- Medical device actuator mechanisms
- Compact packaging machine grippers
- Semiconductor wafer processing equipment
Installation tip:
For optimal performance, align cylinder axis within ±1° of load direction.
Use locknuts (M5) with 0.3–0.6 N·m torque for mounting. Adjust cushion screws
clockwise to increase damping force during final 2mm of stroke.
Avoid side load exceeding 2.5N. For vertical mounting,
maintain ≥70% operating pressure to prevent gravitational drop.
| Property | Property Value |
|---|---|
| sku | MIC16X10SU |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
