Airtac MIC Cushioned Mini Cylinder MIC16X140SCA
AirTAC MIC Series Buffered Miniature Cylinder MIC16X140SCA Specifications
- Model: MIC16X140SCA
- Type: Double-acting with adjustable cushioning
- Bore size: 16mm
- Stroke: 140mm (±0.5mm tolerance)
- Cushion type: Air cushion (adjustable in both directions)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard) with NPT1/8 adaptor option
- Mounting style: Foot-mounted (ISO 6432 compliant)
- Piston material: Hard-anodized aluminum alloy
- Rod material: Chrome-plated steel
- Seal type: NBR + polyurethane hybrid seals
- Weight: 450g ±3% (without accessories)
- Dimensions: 178mm(L) × 25mm(W) × 25mm(H) (fully extended)
- Protection class: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (DOP-free grease)
Ultra-compact cylinder featuring dual-stage buffering technology for smooth end-of-stroke deceleration. The MIC16X140SCA combines high positional accuracy (±0.1mm repeatability) with corrosion-resistant construction, making it ideal for precision automation. Requires 40μm filtered compressed air with 1-10% lubricating oil ratio (ISO 8573-1 Class 4).
- PCB handling robots in electronics assembly
- Pharmaceutical blister packaging machines
- Micro-dispensing systems for adhesives
- Optical lens positioning mechanisms
- Laboratory sample handling automation
Installation note:
Maintain 0.5-1mm alignment tolerance during mounting. For vertical installations,
use counterbalance valves when handling suspended loads exceeding 2kg.
| Property | Property Value |
|---|---|
| sku | MIC16X140SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <140mm> |
