Airtac MK Series Multi-position Locking Cylinder MK10X10
2. Features multiple body mounting configurations for simplified installation;
3. Gang-mounting capability enables multi-cylinder integration, optimizing space utilization in compact layouts;
4. Precision-guided piston rod design eliminates the need for external lubrication;
5. Integrated piston rod locking block ensures anti-rotation stability;
6. Extensive model selection across standardized specifications;
7. Optional high-temperature sealing materials support operation at 0~150℃ (optional feature).
Category: Multi-Position Fixed Cylinders | Brand: AIRTAC | Series: MK
AirTAC MK Series Multi-Position Locking Cylinder MK10X10 Specifications
- Model: MK10X10
- Type: Double-acting multi-position mechanical lock cylinder
- Bore size: 10mm
- Stroke: 10mm
- Operating principle: Pneumatic locking via spring-engaged ball detent
- Working pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5×0.8 (standard) / G1/8 optional
- Locking positions: 3 fixed positions (extended/mid/retracted)
- Cushioning: Adjustable elastic cushioning at both ends
- Body material: Anodized aluminum alloy
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (nitrile rubber)
- Weight: 0.23 kg
- Dimensions: 78mm(L) × 32mm(W) × 32mm(H) (excluding fittings)
- Locking force: 15N (at 0.5MPa)
- Repeat positioning accuracy: ±0.2mm
- Protection rating: IP54
Compact multi-position locking cylinder with integrated mechanical brake mechanism, designed for precision intermediate stopping in automated systems. Features dual-action locking that engages automatically at preset positions when air pressure drops, ensuring fail-safe operation. Pre-lubricated for maintenance-free service.
- Rotary index table positioning in CNC machinery
- Tool changing mechanisms in automated manufacturing cells
- Safety door interlocks for injection molding machines
- Precision workpiece clamping in optical component production
- Stage positioning in semiconductor handling equipment
Installation note:
Mount using M4 screws with 25mm center spacing. Lubricate guide shafts with ISO VG32 hydraulic oil before initial use.
Avoid side-load forces exceeding 5N. For vertical installations, use auxiliary support brackets.
| Property | Property Value |
|---|---|
| sku | MK10X10 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
