Airtac MK Series Multi-position Locking Cylinder MK10X15
2. Features multiple body mounting configurations for simplified installation;
3. Gang-mounting capability enables multi-cylinder integration, optimizing space utilization in compact layouts;
4. Precision-guided piston rod design eliminates the need for external lubrication;
5. Integrated piston rod locking block ensures anti-rotation stability;
6. Extensive model selection across standardized specifications;
7. Optional high-temperature sealing materials support operation at 0~150℃ (optional feature).
Category: Multi-Position Fixed Cylinders | Brand: AIRTAC | Series: MK
AirTAC MK Multi-Position Locking Cylinder MK10X15 Technical Specifications
- Model: MK10X15
- Type: Double-acting multi-position locking cylinder
- Bore size: 10mm
- Stroke: 15mm
- Operating pressure: 0.15–0.8 MPa
- Port size: M5×0.8 (PT1/8 adapter optional)
- Locking positions: 3-5 programmable stops
- Locking force: 18N (at 0.5MPa)
- Piston speed: 50-500mm/s
- Operating temperature: -20℃ to 80℃
- Seal material: Heat-resistant NBR
- Cushioning: Adjustable rubber buffer
- Mounting style: Front/rear flange or foot mounting
- Weight: 0.18kg
- Dimensions: 75mm(L) × 28mm(W) × 28mm(H)
- Protection class: IP40
Precision locking cylinder with electromagnetic position retention capability, featuring a patented mechanical brake system that maintains position during power loss. The chrome-plated piston rod and anodized aluminum body ensure corrosion resistance in humid environments. Requires filtered air (≤5μm) with ISO VG32 lubricant.
- Semiconductor wafer handling robots
- Automated optical inspection (AOI) equipment
- Precision fixture positioning in CNC machining
- Pharmaceutical capsule filling machines
- Battery module assembly systems
Installation note:
Maintain ≤0.05mm perpendicularity tolerance during mounting.
Perform 50-100 no-load cycles before first locking operation.
Use anti-vibration washers in high-frequency applications (>5Hz).
| Property | Property Value |
|---|---|
| sku | MK10X15 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | <15mm> |
