Airtac MK Series Multi-position Locking Cylinder MK10X25
2. Features multiple body mounting configurations for simplified installation;
3. Gang-mounting capability enables multi-cylinder integration, optimizing space utilization in compact layouts;
4. Precision-guided piston rod design eliminates the need for external lubrication;
5. Integrated piston rod locking block ensures anti-rotation stability;
6. Extensive model selection across standardized specifications;
7. Optional high-temperature sealing materials support operation at 0~150℃ (optional feature).
Category: Multi-Position Fixed Cylinders | Brand: AIRTAC | Series: MK
AirTAC MK Series Multi-Position Locking Cylinder MK10X25 Technical Details
- Model: MK10X25
- Type: Compact multi-position lockable air cylinder
- Bore size: 10mm (0.39")
- Stroke: 25mm (0.98")
- Operating pressure: 0.1-0.8 MPa (14.5-116 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Port size: M5x0.8 (dual ports)
- Cushioning: Adjustable air cushion (both ends)
- Mounting: Side-mounted with dual M4 threaded holes
- Cylinder tube: Anodized aluminum alloy
- Piston rod: Stainless steel SUS304
- Seals: NBR (Nitrile rubber)
- Weight: 250g (0.55 lbs)
- Dimensions: 100mm(L) × 40mm(W) × 40mm(H)
- Locking force: 28N at 0.5MPa
- Repeat positioning accuracy: ±0.2mm
Precision locking cylinder with mechanical position memory function, featuring 3-stage adjustable magnetic sensors (optional). The dual-ported design enables bidirectional pressure control with integrated locking grooves for secure mid-stroke positioning. Includes wear-resistant guide bushings and anti-rotation mechanism for angular stability.
- CNC machine tool fixture positioning
- PCB assembly clamping mechanisms
- Pharmaceutical packaging line stoppers
- Automated warehouse sorting gates
- Textile machinery thread guides
Installation guidelines:
Apply ISO VG32 hydraulic oil to rod end before operation.
Maintain 0.3-0.6 MPa working pressure for optimal locking performance.
Allow 1mm clearance around cylinder body for thermal expansion.
- Rod end types: Female thread (standard), clevis, or flange
- Sensor compatibility: 3-wire NPN/PNP (requires MK-S1 bracket)
- Custom stroke lengths available (10-100mm increments)
| Property | Property Value |
|---|---|
| sku | MK10X25 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | <25 mm> |
