Airtac MK Series Multi-position Locking Cylinder MK10X30
The AirTAC Airtac MK Series Multi-position Locking Cylinder MK10X30 is a genuine MK multi-mount cylinder (double acting), 10 mm bore. Its compact square body fixes from six directions and mounts side by side to save space. It delivers about 39.3 N of push force at 0.5 MPa. A bumper cushions the impact. As an MK unit a fixed rod stops the piston rod rotating.
- TypeMulti-mount, double acting
- SeriesMK (no-rotating)
- Bore10 mm
- Push thrust @0.5 MPa39.3 N
- Operating pressure0.2 - 1.0 MPa (28 - 145 psi)
- Port sizeM5x0.8
- CushionBumper
- MagnetWithout magnet
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MK Series Multi-position Locking Cylinder MK10X30
The AirTAC MK10X30 is a compact square-body multi-mount cylinder that fixes from six directions - front, back, left, right, top and bottom - and can be mounted side by side to save space. In double acting form with a 10 mm bore, it gives a theoretical push thrust of 39.3 N at 0.5 MPa, and the 30 mm stroke suits short-travel jobs such as ejecting or stopping small parts. Cushioning is a bumper, and magnetic-switch slots are machined around the body.
This is a genuine AirTAC part from the MK family, where a fixed rod and no-rotating plate stop the piston rod turning - the no-rotating counterpart to the standard MD series. This model code has no trailing S, so the SKU is supplied without a magnet; a magnet-equipped version is listed separately. Operating pressure is 0.2-1.0 MPa (28-145 psi) on air filtered to 40 um. We confirm exact dimensions and sizing from the datasheet on request.
Airtac MK Series Multi-position Locking Cylinder MK10X30 Technical Specifications
| Model | Airtac MK Series Multi-position Locking Cylinder MK10X30 |
|---|---|
| Type | Multi-mount cylinder, double acting |
| Series | MK (no-rotating) |
| Bore | 10 mm |
| Push thrust @0.5 MPa | 39.3 N |
| Port size | M5x0.8 (PT thread) |
| Magnet | Without magnet |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.2 - 1.0 MPa (28 - 145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to 70 C |
| Speed range | 30 - 500 mm/s |
| Cushion | Bumper |
| Mounting | Fix from 6 directions; mountable side by side |
Specifications follow the official AirTAC MD/MK multi-mount data. The front cover and piston are short, so avoid an over-long stroke. An optional high-temperature seal material extends the range to 0 to 150 C. Overall dimensions vary per stroke and allowable side-load is published as curves — ask us and we confirm from the datasheet.
How to choose
The 10 mm bore delivers about 39.3 N of push at 0.5 MPa in double acting form; step up a bore size if you need more thrust. MK over MD is the choice when the rod must not rotate, for example driving a slotted or asymmetric tooling piece. The 30 mm stroke fits within the bore 10 double acting table, which runs up to 35 mm; stay with short travels on this compact body and check side-load capability with us. This SKU has no magnet, and it uses a PT thread - a G-thread, magnet-equipped variant is available.
Applications
Pick-and-place assistance
Push or release small parts at a pick point. The no-rotating rod keeps any attached blade or finger aligned stroke after stroke.
Rotary indexing
Advance parts one pocket at a time on a small indexing dial. The 30 mm stroke matches a single pitch, and side-by-side bodies fit tight dial plates.
Line stopper
Act as a stopper or gate on a light assembly line. Six-direction fixing means the body can be bolted from whichever face the frame allows.
FAQ
When should I pick the MK10X30 instead of an MD cylinder?
Pick MK when the rod must not turn. The MK family adds a fixed rod and no-rotating plate so the piston rod cannot rotate, which matters when driving slotted or asymmetric attachments. An MD cylinder of the same bore allows rotation and gives the same 39.3 N push at 0.5 MPa.
Is a 30 mm stroke sensible on this body?
Yes. The bore 10 double acting table runs up to 35 mm, so 30 mm fits. That said, this is a short-cover compact cylinder, so avoid stretching toward the maximum unless the datasheet confirms it suits your layout, and route side-load questions to us.
