Airtac MK Series Multi-position Locking Cylinder MK10X35
2. Features multiple body mounting configurations for simplified installation;
3. Gang-mounting capability enables multi-cylinder integration, optimizing space utilization in compact layouts;
4. Precision-guided piston rod design eliminates the need for external lubrication;
5. Integrated piston rod locking block ensures anti-rotation stability;
6. Extensive model selection across standardized specifications;
7. Optional high-temperature sealing materials support operation at 0~150℃ (optional feature).
Category: Multi-Position Fixed Cylinders | Brand: AIRTAC | Series: MK
AirTAC MK Series Multi-Position Locking Cylinder MK10X35 Technical Specifications
- Model: MK10X35
- Type: Double-acting multi-position mechanical lock cylinder
- Bore size: Ø10mm
- Stroke: 35mm
- Operating pressure: 0.05-0.9 MPa
- Locking positions: 3 preset positions (extended/mid/retracted)
- Locking force: 19.6N (at 0.5MPa)
- Ambient temperature: -10℃ to 60℃
- Piston speed: 50-700mm/s
- Cushioning: Adjustable elastic cushion
- Port size: M5×0.8 (Rc1/8 optional)
- Body material: Hard anodized aluminum alloy
- Seal material: NBR + Polyurethane
- Weight: 230g ±5%
- Dimensions: 136mm(L) × 22mm(W) × 22mm(H)
- Mounting type: Standard ISO 6432 foot mounting
- Protection class: IP54 (standard), IP67 (optional)
Precision multi-station cylinder with mechanical position memory function, featuring stainless steel locking pins and wear-resistant guide mechanism. The integrated position sensor grooves (optional magnetic switches) enable precise position feedback. Special anti-vibration design maintains position stability under 5G vibration environments.
- Rotary indexing table positioning systems
- PCB board clamping & positioning in SMT machines
- Multi-stage height adjustment in automated packaging
- Tool changing mechanisms in CNC equipment
- Precision alignment in optical component assembly
Installation note:
Requires periodic lubrication (every 500km stroke) with ISO VG32 hydraulic oil.
Maintain minimum 0.3MPa holding pressure for position retention. Avoid side-load
forces exceeding 15N during operation.
| Property | Property Value |
|---|---|
| sku | MK10X35 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | 35mm |
