Airtac MK Series Multi-position Locking Cylinder MK10X40
2. Features multiple body mounting configurations for simplified installation;
3. Gang-mounting capability enables multi-cylinder integration, optimizing space utilization in compact layouts;
4. Precision-guided piston rod design eliminates the need for external lubrication;
5. Integrated piston rod locking block ensures anti-rotation stability;
6. Extensive model selection across standardized specifications;
7. Optional high-temperature sealing materials support operation at 0~150℃ (optional feature).
Category: Multi-Position Fixed Cylinders | Brand: AIRTAC | Series: MK
AirTAC MK10X40 Multi-Position Locking Cylinder Specifications
- Model: MK10X40
- Bore size: Ø10mm
- Stroke: 40mm
- Operation type: Double-acting with mechanical locking
- Locking positions: 3 preset positions (adjustable)
- Working pressure: 0.05–0.9 MPa
- Port size: M5x0.8 (standard) with optional NPT1/8 adapters
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable rubber buffer
- Ambient temperature: -10℃ to 80℃
- Material: Aluminum alloy barrel, hardened stainless steel piston rod
- Seals: NBR/Urethane hybrid seals
- Weight: 380g ±5g
- Dimensions: 156mm(L) × 34mm(W) × 34mm(H) (fully extended)
- Mounting: Standard ISO 6432 base mount with lateral auxiliary brackets
- Protection class: IP54 (standard), IP67 optional
Precision locking cylinder with triple-position memory function, featuring an innovative ratchet-lock mechanism for intermediate stroke fixation. Engineered for applications requiring repeatable mid-stroke stops without pressure maintenance. The anodized barrel resists chemical corrosion in harsh environments.
- Semiconductor wafer handling robots
- Multi-stage press tool positioning
- Automated test equipment with sequenced movements
- Textile machinery thread tension control
- Pharmaceutical blister packaging machines
Installation note:
Engage locking pins before air connection. Lubricate with ISO VG32 turbine oil
during assembly. Requires 5-10 dry cycles to activate anti-jam break-in mode.
- Max lateral load: 15N at mid-stroke
- Position repeat accuracy: ±0.2mm
- Lock release pressure: ≥0.3 MPa
- Cycle life: 2,000,000 cycles (at 0.5 MPa)
| Property | Property Value |
|---|---|
| sku | MK10X40 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | <40mm> |
