Airtac MK Series Multi-position Locking Cylinder MK10X5
2. Features multiple body mounting configurations for simplified installation;
3. Gang-mounting capability enables multi-cylinder integration, optimizing space utilization in compact layouts;
4. Precision-guided piston rod design eliminates the need for external lubrication;
5. Integrated piston rod locking block ensures anti-rotation stability;
6. Extensive model selection across standardized specifications;
7. Optional high-temperature sealing materials support operation at 0~150℃ (optional feature).
Category: Multi-Position Fixed Cylinders | Brand: AIRTAC | Series: MK
AirTAC MK10X5 Multi-Position Locking Cylinder Specifications
- Model: MK10X5
- Type: Double-acting multi-position locking cylinder
- Bore size: 10mm
- Stroke: 5mm (adjustable multi-position)
- Operating pressure: 0.1–0.9 MPa
- Locking force: 35N at 0.5 MPa
- Port size: M5x0.8
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel (SUS304)
- Seal type: NBR wear-resistant seals
- Temperature range: -10℃ to 80℃
- Weight: 0.65kg ±2%
- Dimensions: 120mm(L) × 50mm(W) × 50mm(H)
- Mounting type: 2xM4 threaded holes + front flange
- Cushioning: Adjustable air cushion (both ends)
- Optional accessories: Magnetic switch (D-A93 compatible)
Precision locking cylinder with mechanical position memory function, featuring 5±0.05mm repeat positioning accuracy. The chrome-plated rod and integrated locking mechanism enable stable intermediate stops without air consumption. Ideal for applications requiring precise multi-stage positioning with minimal maintenance.
- PCB board clamping in SMT machinery
- Tool positioning in CNC jig systems
- Multi-stage pressing in automotive assembly
- Position locking in pharmaceutical packaging lines
- Stage positioning in semiconductor handling robots
Installation note:
Apply Molykote 55M grease to sliding surfaces during assembly.
Maintain 0.5-1mm clearance between locking grooves and sensors.
Maximum lateral load: 15N. Lubricate every 500,000 cycles.
| Property | Property Value |
|---|---|
| sku | MK10X5 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | <5mm> |
