Airtac MK Series Multi-position Locking Cylinder MK10X5S
2. Features multiple body mounting configurations for simplified installation;
3. Gang-mounting capability enables multi-cylinder integration, optimizing space utilization in compact layouts;
4. Precision-guided piston rod design eliminates the need for external lubrication;
5. Integrated piston rod locking block ensures anti-rotation stability;
6. Extensive model selection across standardized specifications;
7. Optional high-temperature sealing materials support operation at 0~150℃ (optional feature).
Category: Multi-Position Fixed Cylinders | Brand: AIRTAC | Series: MK
AirTAC MK Series Multi-Position Locking Cylinder MK10X5S Specifications
- Model: MK10X5S
- Type: Double-acting multi-position locking cylinder
- Bore size: 10 mm
- Stroke: 5 mm (standard), customizable up to 50 mm
- Operating pressure: 0.05–1.0 MPa
- Locking positions: 3 fixed points (center/left/right)
- Locking force: 35 N at 0.5 MPa
- Piston speed: 50–700 mm/s
- Temperature range: -10℃ to 70℃
- Mounting style: Standard ISO 6432 foot-mounted
- Cushioning: Adjustable elastic buffer
- Seal material: NBR (nitrile rubber)
- Weight: 180 g ±5% (excluding accessories)
- Dimensions: 105mm(L) × 25mm(W) × 25mm(H) (basic stroke model)
- Port size: M5x0.8 pneumatic thread
- Protection rating: IP54 (standard), IP67 optional
The MK10X5S features a unique mechanical locking mechanism with three precision positions, enabling intermediate stop control without continuous air supply. Its anodized aluminum construction ensures corrosion resistance, while the integrated position sensor slots (optional) allow for automated feedback systems. Requires ISO VG32 turbine oil lubrication for optimal performance.
- Precision fixture positioning in CNC machining centers
- Modular assembly line tooling stations
- Semiconductor wafer handling equipment
- Pharmaceutical blister packaging machines
- Robotic end-effector position memory systems
Installation protocol:
Maintain 0.5mm minimum clearance between cylinder body and adjacent components.
Locking pins require manual release via side access port before initial operation.
Lubricate guide shafts every 500,000 cycles using specified grease (AIRTAC LG-100).
| Property | Property Value |
|---|---|
| sku | MK10X5S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | <5mm> |
