Airtac MK Series Multi-position Locking Cylinder MK16X10
2. Features multiple body mounting configurations for simplified installation;
3. Gang-mounting capability enables multi-cylinder integration, optimizing space utilization in compact layouts;
4. Precision-guided piston rod design eliminates the need for external lubrication;
5. Integrated piston rod locking block ensures anti-rotation stability;
6. Extensive model selection across standardized specifications;
7. Optional high-temperature sealing materials support operation at 0~150℃ (optional feature).
Category: Multi-Position Fixed Cylinders | Brand: AIRTAC | Series: MK
AirTAC MK16X10 Multi-position Locking Cylinder Technical Details
- Model series: MK (Compact multi-position locking type)
- Bore size: 16mm (Standard ISO cylinder sizing)
- Stroke: 10mm (Adjustable with position lock)
- Operating pressure: 0.05-0.9 MPa
- Locking positions: 3-5 preset positions (User-configurable)
- Locking force: 12N at 0.5MPa
- Piston speed: 50-500mm/s
- Mounting type: Basic type (Accessory brackets optional)
- Cushioning: Elastic rubber buffer + adjustable air cushion
- Rod end: Male thread M6×1.0
- Seal material: HNBR (Hydrogenated Nitrile) for high temperature resistance
- Ambient temperature: -10℃ to 80℃ (No freeze)
- Weight: 280g ±5% (Without accessories)
- Dimensions: 120mm(L) × 34mm(W) × 34mm(H) (Cylinder body only)
- Port size: M5×0.8 (Dual ports for forward/return stroke)
- Repeat positioning accuracy: ±0.2mm
Precision multi-station cylinder featuring mechanical locking mechanism with spring-assisted position retention. The anodized aluminum construction provides corrosion resistance in humid environments. Integrated magnetic sensor slots (Φ4.5) enable position feedback when used with proximity switches. Requires ISO VG32 hydraulic oil mist lubrication for optimal seal life.
- Rotary indexing table positioning in assembly machines
- Tooling plate height adjustment in CNC fixtures
- Multi-stage press mechanisms for electronic component manufacturing
- Packaging machine stopper position control
- Medical device testing equipment with intermediate hold positions
Installation protocol:
Locking pins must engage fully before operation. Lubricate through air port using
ISO VG32 oil at 1 drop/3 cycles during initial setup. Avoid side-load exceeding 3N·m.
Critical note:
Position locking requires minimum 0.3MPa pressure maintenance. Do not disassemble
locking mechanism without factory-approved tooling (P/N: MK-TK02).
| Property | Property Value |
|---|---|
| sku | MK16X10 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
